Control Panel
81
4
Data LED 4
The LED is a light which show the printer status.
Data LED (Yellow)
4
LCD 4
The LCD shows the current printer status. When you use the buttons on the control panel, the LCD will
change.
If there are any problems, the LCD will show the error message, maintenance message or call service
message so you will know that you need to take action. (For more information about these messages, see
LCD messages on page 127.)
Back light 4
LED indication Meaning
On Data is in the printer memory.
Blinking Receiving or processing data.
Off No remaining data in the memory.
Light Meaning
Off The printer is off or in sleep status.
Green (General) Ready to print
Printing
Warming up
Job canceling
Red (Error) There is a problem with the printer.
Orange (Setting) Choosing a menu (Control panel menu or Reprint menu)
Pause
