Brother MFC-5440CN - Control Panel

2
(For MFC-5440CN)
(For MFC-5840CN)
Control Panel
1. Print keys 5. Mode keys 9. Navigation keys
2. Fax and telephone keys 6. Stop/Exit key 10. Liquid Crystal Display (LCD)
3. Copy keys 7. Start keys
4. Dial Pad 8. On/Off key
For the details of the control panel, see "Control panel overview" in Chapter 1 of the User’s Guide.
1. Photo keys 5. Mode keys 9. Navigation keys
2. Fax and telephone keys 6. Stop/Exit key 10. Liquid Crystal Display (LCD)
3. Copy keys 7. Start keys 11. Print key
4. Dial Pad 8. On/Off key
For the details of the control panel, see "Control panel overview" in Chapter 1 of the User’s Guide.
4 5 6 721 3
10 9 8
11
4 5 6 721 3
10 9 8
