Brother MFC-7360N Quick Setup Guide

19
Windows
®
Wired Network
Windows
®
Macintosh
Wired Network
d When the Firewall/AntiVirus detected screen
appears, choose Change the Firewall port
settings to enable network connection and
continue with the installation.
(Recommended) and click Next.
(Not for Windows
®
2000 users)
If you are not using the Windows
®
Firewall, see
the user's guide of your firewall or antivirus
software for information on how to add the
following network ports.
 For network scanning, add UDP port 54925.
 For network PC-Fax receiving, add UDP port
54926.
 If you still have trouble with your network
connection, add UDP port 137.
e Follow the on-screen instructions to complete
setup.
19
Install MFL-Pro Suite on
additional computers
(if needed)
If you want to use your machine with multiple
computers on the network, install MFL-Pro Suite on
each computer. Go to step 18 on page 18.
IMPORTANT
DO NOT cancel any of the screens during the
installation. It may take a few seconds for all
screens to appear.
Note
• If your machine is not found over the network,
confirm your settings by following the on-screen
instructions.
• You can find your machine’s IP address and the
node name by printing out the Network
Configuration Report. See Print the Network
Configuration Report on page 22.
• For Windows Vista
®
and Windows
®
7 users,
when the Windows Security screen appears,
click the check box and click Install to complete
the installation correctly.
• If an error message appears during the
software installation, run the
Installation Diagnostics located in
Start/All Programs/Brother/MFC-XXXX LAN
(where MFC-XXXX is your model name).
Note
Network license (Windows
®
)
This product includes a PC license for up to
5 users. This license supports the installation of
the MFL-Pro Suite including ScanSoft™
PaperPort™ 12SE or ScanSoft™ PaperPort™
11SE on up to 5 PCs on the network. If you want
to use more than 5 PCs with ScanSoft™
PaperPort™ 12SE or ScanSoft™ PaperPort™
11SE installed, please purchase the Brother NL-5
pack which is a multiple PC license agreement
pack for up to 5 additional users. To purchase the
NL-5 pack, contact your authorized Brother
dealer or contact Brother customer service.
Finish
The installation is now
complete.
Note
• If you use a specified IP Address for the
machine, you must set the Boot Method to
Static by using the control panel. For more
information, see Network menu in the Network
User's Guide.
• Depending on your security settings, a
Windows Security or antivirus software window
may appear when using the machine or its
software. Please allow or permit the window to
continue.
• XML Paper Specification Printer Driver
The XML Paper Specification Printer Driver is
the most suitable driver for Windows Vista
®
and
Windows
®
7 when printing from applications
that use the XML Paper Specification
documents. Please download the latest driver
by accessing the Brother Solutions Center at
http://solutions.brother.com/
.

Brother MFC-7360N Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Scan to	E-mail, File, Image, OCR
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Dimensions (WxDxH)	405 x 399 x 316 mm
All-in-one functions	Copy, Fax, Print, Scan
Compatible operating systems	Linux Mac OS X 10.4.11, 10.5.x, 10.6x Windows 7, Vista, XP, 2000
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	14.4 Kbit/s
Fax speed dialing (max numbers)	208
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	32 MB
Processor family	ARM
Compatible memory cards	Not supported
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	0.9 W
Power consumption (PowerSave)	65 W
Power consumption (average operating)	495 W
Package weight	14800 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	10000 pages per month
