Brother MFC-8535DN Service Manual

3-6
Confidential
Eject motor plate Taptite bind B M3x10 2 0.50.1 (51)
Eject motor Screw bind M3x4 1 0.650.05 (6.50.5)
Bottom frame L
(T1: Models with 520-sheet)
Taptite bind B M4x30
3
0.80.1 (81)
Base plate Screw pan (S/P washer)
M3x12DB
2
0.60.1 (61)
Taptite bind B M4x12 4 0.80.1 (81)
High-voltage power supply PCB ASSY Taptite bind B M4x12 2 0.80.1 (81)
T1 paper feed actuator holder ASSY Taptite bind B M3x10 1 0.50.1 (51)
Main frame R Taptite bind B M4x12 5 0.80.1 (81)
MP feed frame Taptite bind B M3x10 2 0.50.1 (51)
MP paper empty sensor PCB ASSY Taptite bind B M3x10 1 0.50.1 (51)
Paper empty sensor PCB ASSY Taptite bind B M3x10 1 0.50.1 (51)
LT side cover L Taptite bind B M4x12 2 0.80.1 (81)
LT side cover R Taptite bind B M4x12 2 0.80.1 (81)
LT front cover ASSY Taptite cup S M3x8 SR 1 0.80.1 (81)
Under bar front
(Models with 520-sheet)
Taptite bind B M4x12
2
0.80.1 (81)
Under bar ground plate L (520) Taptite cup S M3x8 SR 1 0.80.1 (81)
Under bar front
(Models with 250-sheet)
Taptite bind B M4x12 2 0.80.1 (81)
Taptite cup S M3x8 SR
(3a)
1
0.80.1 (81)
Taptite cup S M3x8 SR
(3b)
1
0.60.1 (61)
Under bar Taptite bind B M4x12 2 0.80.1 (81)
Center FG plate L Taptite cup S M3x8 SR
(5a)
1
0.80.1 (81)
Taptite cup S M3x8 SR
(5b)
1
0.60.1 (61)
Under bar ground plate L (250) Taptite cup S M3x8 SR 2 0.80.1 (81)
LT frame L unit Taptite bind B M4x12 4 0.80.1 (81)
Taptite cup S M3x8 SR
(7a)
4
0.80.1 (81)
Taptite cup S M3x8 SR
(
7b)
2
0.60.1 (61)
LT drive ASSY Taptite bind B M4x12 3 0.80.1 (81)
Center FG plate R Taptite cup S M3x8 SR
(1a)
1
0.80.1 (81)
Taptite cup S M3x8 SR
(1b)
1
0.60.1 (61)
LT paper feed frame Taptite cup S M3x8 SR 4 0.60.1 (61)
Paper feed frame FG
plate R
1
0.60.1 (61)
LT front beam Taptite bind B M4x12 2 0.80.1 (81)
LT paper feed actuator holder ASSY Taptite bind B M3x10 1 0.50.1 (51)
LT paper empty sensor PCB ASSY Taptite bind B M3x10 1 0.50.1 (51)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
