Page #175 background image

Loading...

Page #175 background image

3-15

Confidential

5

Document scanner unit

Harness colors are subject to change for some reason.

First side CIS flat cable

First side CIS unit

FB motor harness (YW)

FB FG harness (YW)

USB host PCB

ASSY

Panel flat cable

USB host harness (GY)

Panel FG harness

(WH)
