Brother MFC-J200 Service Manual

1-7
Confidential
8 SUPPLIES/OPTIONS
9 SERVICE INFORMATION
Model
DCP-J100
DCP-J105
DCP-J132W
DCP-J152W
DCP-J172W
DCP-T300
DCP-T500W
DCP-T700W
MFC-J200 MFC-J245 MFC-T800W
Ink
Cartridge
Yield @
ISO/IEC
19752
pattern
Bundled
Cartridges
BK: 2,200
CL: 1,000
(pages)
BK: 240 CL:
240 (pages)
N/A
BK: 2,200
CL: 1,000
(pages)
BK: 240
CL: 240
(pages)
N/A
Supply Standard
Cartridges
N/A
BK: 300 CL:
300 (pages)
N/A
BK: 300
CL: 300
(pages)
N/A
Supply High
Yield Cartridges
N/A
BK: 600 CL:
600 (pages)
N/A
BK: 600
CL: 600
(pages)
N/A
Supply Super
High Yield
Cartridges
BK: 2,400
CL: 1,300
(pages)
N/A
BK: 2,400
CL: 1,300
(pages)
N/A N/A
Ink Bottle
Yield @
ISO/IEC
19752
pattern
Bundled Bottles
N/A
BK: 5,400
CL: 4,500
(pages)
N/A
BK: 5,400
CL: 4,500
(pages)
Supply High
Yield Bottle
N/A
BK: 6,000
CL: 5,000
(pages)
N/A
BK: 6,000
CL: 5,000
(pages)
Storage Condition of Ink
Cartridge
(Temperature) Normal condition: -20 to 40 °C
(Humidity) Normal condition: 20 to 80 %
*Storage condition at the temperature of 40 to 50 °C and the humidity of 80 to 95 %: UP to 5 days
*Storage condition at the temperature of 40 to 60 °C and the humidity of Non controll condition to: UP to 5 days
Model
DCP-J100
DCP-J105
DCP-J132W
DCP-J152W
DCP-J172W
DCP-T300
DCP-T500W
DCP-T700W
MFC-J200 MFC-J245 MFC-T800W
Monthly Volume 2,500 pages 1,250 pages 2,500 pages 2,500 pages 1,250 pages 2,500 pages
Machine Life
30,000 pages
or 5 years
15,000 pages
or 5 years
30,000 pages
or 5 years
30,000 pages
or 5 years
15,000 pages
or 5 years
30,000 pages
or 5 years
MTBF
(Mean Time Between
Failures)
4,000 hours
MTTR
(Mean Time To Be Repaired)
30 minutes

Brother MFC-J200 Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	10 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, File, Image, OCR
Scan drivers	ICA, TWAIN, WIA
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	Color faxing
Modem speed	14.4 Kbit/s
Fax coding methods	JBIG
Fax resolution (black)	203 x 196 DPI
Fax transmission speed	170 sec/page
Fax speed dialing (max numbers)	40
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Paper input type	Paper tray
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Envelopes sizes	10, C5, DL, Monarch
Photo paper sizes	10x15, 13x18 cm
Custom media width	98 - 215.9 mm
Custom media length	148 - 297 mm
Paper tray media types	Coated paper, Envelopes, Glossy paper, Plain paper, Transparencies
Non-ISO print media sizes	2L, Executive (184 x 267mm), Index card
ISO A-series sizes (A0...A9)	A4, A5, A6
Borderless printing media sizes	10x15, 2L, A4, A6, Index card, Letter
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black
Market positioning	Home & office
Display number of lines	1 lines
Display number of characters	16
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK, WPS
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, FTP Server, SNMPv1/v2c, TFTP server, ICMP, Web Services
Direct printing	-
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Sound pressure level (printing)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	3 W
Power consumption (PowerSave)	1.1 W
Power consumption (average operating)	16 W
Fax compatibility	ITU-T G3
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	374 mm
Width	435 mm
Height	180 mm
