Brother MFC-J4410DW Quick Setup Guide

29
For Wireless Network Users
Wireless Network
19
Setup using the
installation CD-ROM and
a USB cable (Windows
®
and Macintosh)
a Put the supplied installation CD-ROM into your
CD-ROM drive. If the model name screen
appears, choose your machine. If the language
screen appears, choose your language.
b The CD-ROM Top menu will appear.
Click Install MFL-Pro Suite and click Yes if
you accept the license agreements. Follow the
on-screen instructions.
c Choose Wireless Network Connection, and
then click Next.
d When this screen appears, choose Change
the Firewall port settings to enable network
connection and continue with the
installation. (Recommended) and click Next.
If you are using a firewall other than the
Windows
®
Firewall or the Windows
®
Firewall is
off, this screen may appear.
See the instructions provided with your firewall
software for information on how to add the
following network ports.
 For network scanning, add UDP port 54925.
 For network PC-Fax receiving, add UDP port
54926.
 If you still have trouble with your network
connection, add UDP ports 137 and 161.
• You need to temporarily use a USB cable
during configuration (cable not included).
• These steps are for a Windows
®
installation.
For Macintosh installation, insert the
installation CD-ROM into your CD-ROM
drive and double-click Start Here OSX to
install. Select Wireless installation and
follow the Wireless Device Setup
instructions on your computer screen.
NOTE
• For Windows Vista
®
and Windows
®
7, when
the User Account Control screen appears click
Continue or Yes.
• If the Brother screen does not appear
automatically, go to My Computer or
Computer then double-click the CD-ROM icon
and double-click start.exe.

Brother MFC-J4410DW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	18 ipm
Print speed (ISO/IEC 24734) color	16 ipm
Duplex print speed (ISO/IEC 24734) mono	6 ipm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	25 ppm
All-in-one functions	Copy, Fax, Print, Scan
Networking standards	IEEE 802.3, IEEE 802.3u
Color all-in-one functions	copy, fax, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 1000 pages per month
Number of print cartridges	4
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	20 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	2400 x 2400 DPI
Faxing	Color faxing
Fax memory	200 pages
Modem speed	336 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	203 x 392 DPI
Fax transmission speed	3.37 sec/page
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	50 sheets
Total number of input trays	-
Auto document feeder (ADF) input capacity	20 sheets
Photo paper sizes	9x13, 10x15, 13x18 cm
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Paper tray media types	Envelopes, Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	4x6, 5x7, 5x8, 3.5x5 \
Borderless printing media sizes	4x6, 5x7, A3, A4, A6, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 105 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, Ivory
Display diagonal	1.8 \
Market positioning	Home & office
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Compatible memory cards	Memory Stick (MS), MMC, MMC+, MS Duo, MS PRO, SD, SDHC
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.4 W
Power consumption (standby)	5.5 W
Power consumption (PowerSave)	1.5 W
Power consumption (average operating)	21 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	266 mm
Package width	564 mm
Package height	416 mm
Package weight	11500 g
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)

Weight and Dimensions

Depth	290 mm
Width	480 mm
Height	186 mm
