Brother MFC-J4710DW Quick Setup Guide

31
For Wireless Network Users
Wireless Network
20
Setup using the
installation CD-ROM and
a USB cable (Windows
®
and Macintosh)
a Put the supplied installation CD-ROM into your
CD-ROM drive. If the model name screen
appears, choose your machine. If the language
screen appears, choose your language.
b The CD-ROM Top menu will appear. Click
Install MFL-Pro Suite and click Yes if you
accept the license agreements. Follow the
on-screen instructions.
c Choose Wireless Network Connection, and
then click Next.
d When this screen appears, choose Change
the Firewall port settings to enable network
connection and continue with the
installation. (Recommended) and click Next.
If you are using a firewall other than the
Windows
®
Firewall or the Windows
®
Firewall is
off, this screen may appear.
See the instructions provided with your firewall
software for information on how to add the
following network ports.
 For network scanning, add UDP port 54925.
 For network PC-Fax receiving, add UDP port
54926.
 If you still have trouble with your network
connection, add UDP ports 137 and 161.
• You need to temporarily use a USB cable
during configuration (cable not included).
• These steps are for a Windows
®
installation.
For Macintosh installation, insert the
installation CD-ROM into your CD-ROM
drive and double-click Start Here OSX to
install. Select Wireless installation and
follow the Wireless Device Setup
instructions on your computer screen.
NOTE
• For Windows Vista
®
and Windows
®
7, when
the User Account Control screen appears click
Continue or Yes.
• If the Brother screen does not appear
automatically, go to My Computer or
Computer then double-click the CD-ROM icon
and double-click start.exe.

Brother MFC-J4710DW Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	20 ipm
Print speed (ISO/IEC 24734) color	18 ipm
Duplex print speed (ISO/IEC 24734) mono	6 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 1000 pages per month
Number of print cartridges	4
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	17 cpm
Copy speed (color, normal quality, A4)	14 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	2400 x 2400 DPI
Faxing	Color faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	203 x 392 DPI
Fax transmission speed	3.37 sec/page
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	50 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	20 sheets
Photo paper sizes	9x13, 10x15, 10x18 cm
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	4x6, 5x7, 5x8, 3.5x5 \
Borderless printing media sizes	4x6, 5x7, A3, A4, A6, Legal
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, Ivory
Display diagonal	3.7 \
Market positioning	Home & office
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, TKIP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPS
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Compatible memory cards	MMC, MMC+, MS Duo, MS Micro (M2), MS PRO, MS PRO Duo, SD, SDHC, SDXC
Sound pressure level (printing)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	1.5 W
Power consumption (PowerSave)	5.5 W
Power consumption (average operating)	21 W
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	329 mm
Package width	564 mm
Package height	416 mm
Package weight	14000 g

Weight and Dimensions

Depth	290 mm
Width	480 mm
Height	254 mm
