If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Flickr
®
:
- To download your own documents from the service, press [Your album].
- To download other users’ documents from the service, press [Other user's album], and then
enter the account name of the user whose documents you want to download.
6. Follow the on-screen instructions to complete this operation.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [Show Unsorted Files] or [Show Unsorted Photos] to select documents. You cannot
download documents from other users if the documents are not saved in an album.
MFC-J2730DW/MFC-J5730DW/MFC-J5930DW
1. Insert a USB flash drive into your machine.
The LCD screen automatically changes.
2. Press [Web].
If information regarding the Internet connection appears on the machine's LCD, read the information
and press [OK].
Occasionally, updates or announcements about Brother Web Connect's features will appear on the
LCD. Read the information, and then press [OK].
3. Swipe left or right or press d or c to display the service that hosts the document you want to download.
Press the service name.
4. Do one of the following:
To log on to the service with your account, swipe up or down or press a or b to display your account
name, and then press it. If the PIN entry screen appears, enter the four-digit PIN and press [OK].
To access the service as a guest user, swipe up or down or press a or b to display [Use Service as a
Guest User], and then press it. When the information regarding access as a guest user appears, press
[OK].
5. Press [Download to Media].
If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Flickr
®
:
- To download your own documents from the service, press [Your album].
- To download other users’ documents from the service, press [Other user's album], and then
enter the account name of the user whose documents you want to download.
6. Follow the on-screen instructions to complete this operation.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [Show Unsorted Files] or [Show Unsorted Photos] to select documents. You cannot
download documents from other users if the documents are not saved in an album.
Related Information
Brother Web Connect
536

Table of Contents

Other manuals for Brother MFC-J5335DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J5335DW and is the answer not in the manual?

Brother MFC-J5335DW Specifications

General IconGeneral
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle30000 pages per month
Recommended duty cycle250 - 2000 pages per month
Number of print cartridges4
Print technologyInkjet
Maximum resolution4800 x 1200 DPI
Poster printing functionYes
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Time to first page (black, normal)5.5 s
Time to first page (color, normal)6 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)28 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 4800 DPI
Maximum number of copies99 copies
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)12 cpm
Copy speed (color, normal quality, A4)9 cpm
Scan toE-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner typeFlatbed scanner
Grayscale levels256
Input color depth48 bit
Maximum scan area215.9 x 297 mm
Output color depth24 bit
Scan speed (black)14 inch/min
Image formats supportedJPEG XR, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedPDF
Optical scanning resolution1200 x 2400 DPI
Fax memory200 pages
Modem speed14.4 Kbit/s
Fax speed dialing (max numbers)100
Photo paper sizes9x13, 10x15, 13x18 cm
Paper tray media typesCoated paper, Glossy paper, Plain paper, Recycled paper
Paper tray media weight64 - 220 g/m²
ISO A-series sizes (A0...A9)A3, A4, A5, A6
ISO C-series sizes (C0...C9)C5
Photo paper sizes (imperial)3.5x5, 4x6, 5x7 \
Multi-purpose tray media typesGlossy paper, Plain paper, Recycled paper
Borderless printing media sizesA3, A4, Ledger
Maximum ISO A-series paper sizeA3
Auto Document Feeder (ADF) media weight64 - 120 g/m²
Email protocolsAPOP, IMAP4, POP3, SMTP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, FTPES, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSID, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS Name Resolution, DNS Resolver, mDNS, LLMNR Responder, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Client and Server, SNMPv1/v2c, TFTP server, SMTP Client, ICMP, Web Services (Print/Scan), CIFS Client, SNTP Client, POP3, IMAP4, HTTP Server
Supported network protocols (IPv6)(Turned off as defalut) NDP, RA, mDNS, LLMNR Responder, DNS Resolver, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Client/Server, SNMPv1/v2, TFTP server, Web Services (Print/Scan), SMTP Client, POP3, CIFS Client, SNTP Client, IMAP4, ICMPv6, HTTP Server
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal2.7 \
Market positioningBusiness
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Card reader integratedNo
Sound power level (standby)50 dB
Power consumption (off)0.04 W
Power consumption (ready)5 W
Power consumption (sleep)1.6 W
Power consumption (copying)31 W
Power consumption (standby)6.5 W
Power consumption (average operating)29 W
Sustainability certificatesBlue Angel, ENERGY STAR
Package depth467.36 mm
Package width637.54 mm
Package height436.88 mm
Package weight20500 g
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Paper input typePaper tray
Total input capacity250 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth398 mm
Width530 mm
Height304 mm
