Brother MFC-J5730DW User Manual

Brother MFC-J5730DW
814 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #655 background imageLoading...
Page #655 background image
Difficulties Suggestions
See Related Information: Change the Paper Size and Paper Type.
If you use glossy photo paper, make sure the paper type setting is correct.
Stains appear on the reverse side
or at the bottom of the page.
Make sure the printer platen is not dirty with ink.
See Related Information: Clean the Machine's Printer Platen.
Make sure you are using Brother Original ink.
Make sure you are using the paper support flap.
See Related Information: Load Paper.
Make sure the paper feed rollers are not dirty with ink.
See Related Information: Clean the Paper Feed Rollers.
The machine prints dense lines on
the page.
Windows
®
Select Reverse Order in the Basic tab of the printer driver.
The printouts are wrinkled.
Windows
®
In the printer driver, choose the Advanced tab, click Other Print Options,
and then click Advanced Colour Settings. Clear the Bi-Directional Printing
check box.
Macintosh
In the printer driver, choose Print Settings, click Advanced, choose Other
Print Options, and clear the Bi-Directional Printing check box.
Make sure you are using Brother Original ink.
Paper Handling Difficulties
Difficulties
Suggestions
The machine does not feed paper. Make sure the paper tray is pushed in all the way until it locks into place.
Make sure the Jam Clear Cover at the back of the machine is closed.
If the machine's LCD displays a Paper Jam message and you still have a
problem, see Related Information: Error and Maintenance Messages.
If the paper tray is empty, load a new stack of paper into the paper tray.
If there is paper in the paper tray, make sure it is straight. If the paper is curled,
straighten it. Sometimes it is helpful to remove the paper, turn the stack over and
put it back in the paper tray.
Reduce the amount of paper in the paper tray, and then try again.
Clean the paper pick-up rollers.
See Related Information: Clean the Paper Pick-up Rollers.
Make sure that the paper is within specifications for the machine.
See Related Information: Paper Weight and Thickness.
Photo paper does not feed
correctly.
When you print on Brother Photo paper, load one extra sheet of the same photo
paper in the paper tray. An extra sheet has been included in the paper package
for this purpose.
Machine feeds multiple pages. Make sure the paper is loaded correctly in the paper tray.
Remove all the paper from the tray and fan the stack of paper well, then put it
back in the tray.
Make sure you do not push the paper in too far.
See Related Information: Load Paper.
Make sure the Jam Clear Cover is closed correctly.
See Related Information: Printer Jam or Paper Jam.
Make sure the Base Pad in the paper tray is not dirty.
See Related Information: Clean the Base Pad.
648

Table of Contents

Other manuals for Brother MFC-J5730DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J5730DW and is the answer not in the manual?

Brother MFC-J5730DW Specifications

General IconGeneral
Duplex printingYes
Print technologyInkjet
Maximum resolution1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Time to first page (black, normal)6 s
Duplex print speed (ISO/IEC 24734) mono12 ipm
Duplex print speed (ISO/IEC 24734) color11 ipm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Copy speed (black, normal quality, A4)12 cpm
Copy speed (color, normal quality, A4)9 cpm
Scan toE-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner typeFlatbed & ADF scanner
Input color depth48 bit
Maximum scan area210 x 297 mm
Output color depth24 bit
Scan speed (color)14 ppm
Maximum scan resolution19200 x 19200 DPI
Duplex scan speed (color)10 ppm
Optical scanning resolution1200 x 1200 DPI
FaxingMono faxing
Fax memory200 pages
Modem speed33.6 Kbit/s
Fax speed dialing (max numbers)100
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal3.66 \
Market positioningBusiness
Internal memory256 MB
Card reader integratedNo
Sound pressure level (printing)50 dB
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Package depth469 mm
Package width639 mm
Package height511 mm
Package weight24300 g
Power consumption (off)0.04 W
Power consumption (sleep)1.6 W
Power consumption (standby)6.5 W
Power consumption (average operating)30 W
Sustainability certificatesBlue Angel, ENERGY STAR
Email protocolsAPOP, POP3
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Security algorithms64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity100 sheets
Maximum input capacity500 sheets
Total number of input trays2
Auto document feeder (ADF) input capacity50 sheets
Digital sender-
Maximum duty cycle- pages per month
Paper tray media typesPlain paper, Thin paper
ISO A-series sizes (A0...A9)A3, A4
Maximum ISO A-series paper sizeA3
Bundled softwareBrother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth398 mm
Width530 mm
Height374 mm
