EDITING A LABEL
17
Setting Label Attributes ([Length]/[Margin]/[Tab Length])
Setting Label Attributes ([Length]/[Margin]/[Tab Length])
(Refer to “Adjusting the Label Length” on page 23, “Setting Margin” on
page 21 and “To change tab length:” on page 10.)
[Length] can be set within the range 30 mm - 300 mm. When [Auto] is
selected, the length of the label is automatically adjusted based on the
amount of text entered.
Creating a Bar Code Label
• The P-touch labeler is not designed exclusively for creating bar code
labels. Always check that bar code labels can be read by the bar code
reader.
• For best results, print bar code labels in black ink on white tape.
Some bar code readers may not be able to read bar code labels
created using colored tape or ink.
• Use the [Large] setting for [Width] whenever possible. Some bar code
readers may not be able to read bar code labels created using the
[Small] setting.
• Continuously printing a large number of labels with bar codes can
overheat the print head, which may affect printing quality.
Setting Bar Code Parameters and Entering Bar Code Data
• Symbols are only available for the CODE39, CODE128, CODABAR
or GS1-128 protocols. When not using symbols, after typing in the
bar code data, press ( ) or ( ) to insert the bar code in the label.
• The "C.Digit" (Check Digit) attribute is only available for the CODE39,
I-2/5 and CODABAR protocols.
• Only one bar code can be printed on a label.
() / Select an attribute / Set a value for that attribute ()
or ( ).
() / [Bar Code Setup] ( ) or ( ) / Select an attribute
/ Set a value for that attribute ( ) or ( ) Type in the bar code
data
() / Select a character ( ) or ( ) () or
().
