Brother P-touch PT-D400 P-touch PTD400AD User Manual

22
Setting Margin
LABEL PRINTING
 [Chain]
Use this setting when printing several labels with minimum margins.
NOTE
• When [Chain] is set, feed the tape before using the cutter otherwise
a part of the text may be cut off. Refer to “Feeding Tape” on page 9.
• The value XX displayed on the upper right corner of the LCD display
indicates the label length XX shown on the Label images below.
• Do not pull the tape since this may damage the tape cassette.
Enter text (ABC)  ()  / [Margin]  / [Chain]  () or
()
 ()  / Select the number of copies  (), () or
()
 The message [OK to Feed?] appears  ()  Clear the text and
enter text for the next label (DEF)
 ()  / Select the number of copies
 ( ), ( ) or ( )  The message [OK to Feed?] appears  () or
( ) to feed the tape.
ABC
DEF
9.5 mm
LCD display Label image
Full
Half
Narrow
ABC
XX mm
ABC
XX mm
ABC
XX mm
w ww. . com
information@itm.com1.800.561.8187

Brother P-touch PT-D400 P-touch PTD400AD Specifications

General

Model	PT-D400
Keyboard	QWERTY
Print Resolution	180 dpi
Print Speed	20mm/sec
Cutter	Manual
Print Technology	Thermal Transfer
Display	LCD
Tape Width	6mm, 9mm, 12mm, 18mm
Tape Sizes	3.5mm, 6mm, 9mm, 12mm, 18mm
Power Source	AC Adapter or Battery
Memory	50 labels
Dimensions	188mm x 177mm x 72mm
