8
Power Supply and Tape cassette
GETTING STARTED
NOTE
• When using AC adapter (AD-E001):
x Insert the plug on the adapter cord into the AC adapter jack on the
side of the machine.
x Insert the plug into the nearest standard electrical outlet. For
memory back up, we recommend using AA alkaline batteries (LR6)
or Ni-MH batteries (HR6) together when using the AC adapter.
• To safeguard and backup the P-touch labeler’s memory, when the
AC adapter is unplugged it is recommended to have AA alkaline
batteries (LR6) or Ni-MH batteries (HR6) installed in the P-touch
labeler.
• When power is disconnected for more than two minutes, all text and
format settings will be cleared. Any text files stored in the memory will
also be cleared.
• Remove the batteries if you do not intend to use the P-touch labeler
for an extended period of time.
• Dispose of the battery at an appropriate collection point, not in the
general waste stream. In addition, be sure to observe all applicable
federal, state, and local regulations.
• When storing or discarding the battery, wrap it (for example with
cellophane tape), to prevent it from short-circuiting.
(Battery insulation example)
1. Cellophane tape
2. Alkaline or Ni-MH battery
Insert a Tape Cassette.
1
2
CAUTION
USING A COMBINATION OF DIFFERENT BATTERIES (SUCH AS Ni-MH AND
ALKALINE), MAY RESULT IN AN EXPLOSION. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
Tape cassette
compartment
Release lever
Tape cutter
Tape exit slot
Tape compartment cover
Tape cutter lever
Print head
Keyboard
LCD display
To Next Page
