Screen overview
The basic operation flow is shown below.
In the pattern type selection screen, select
a pattern type. (Refer to page 23, 50)
1 Touch this key to continue to the pattern
editing screen. This key is not available
unless a pattern type is selected.
In the embroidering settings screen , if it is a
combined pattern , edit the entire pattern, specify the
embroidering settings and check the embroidery area.
(Refer to page
26, 54 )
1 Touch this key to quit the current operation
and return to the pattern type selection
screen.
2
Touch this key to return to the pattern editing
screen
.
3 Touch this key to continue to the embroidering
screen
.
In the pattern editing screen, edit the
pattern. (Refer to page 25, 52)
1 Touch this key to return to the pattern type
selection screen and add another pattern.
2 Touch this key to continue to the
embroidering settings screen.
In the pattern list screen, select the
pattern. (Refer to page 23, 51)
1 Touch this key to return to the pattern type
selection screen.
2 Touch this key to continue to the pattern
editing screen.
In the embroidering screen , check the thread
colors assigned to the needle bars, and then install
the upper threads.Touch the unlock key so
that the start/stop button starts flashing in green and
the embroidery machine is ready to begin sewing.
After the embroidery is sewn, the
embroidering
settings screen
appears. (Refer to page 33, 56)
1 Touch this key to return to the embroidering
settings screen.
