Power Amplifiers Types 2716 and 2716-C –
User Manual
10
3.4 Grounding
The amplifier’s signal ground and chassis ground (protective earth) are not directly connected
to each other in order to prevent ground-loop interference. However, internal components
ensure that the potential difference between chassis and signal ground does not exceed
approximately 0.6V. These components are two antiparallel power diodes and a 100Ω resistor.
If, however, you wish to tie the signal ground to chassis, connect the XLR-connector’s shell
lug to pin 1. In the interest of safety, never disconnect the earth pin on the AC power cord.
Table 3.1 Power Consumption values
Maximum Output Power Mains Input Power
Power [W]
Full Power
Sine Wave [W]
Idle [W]
8 ohms 2× 110 300 30
4 ohms 2× 160 800 30
2 ohms 2× 200 900 30
BE169212.book Page 10 Tuesday, January 23, 2007 9:00 AM
