BRUEL & KJAER 2716 User Manual

11
Chapter 4
Connections
4.1 Input connections
4.1.1 Balanced Inputs
XLR Input connectors are active balanced and wired according to the IEC 268, i.e., pin 2
hot, and wired in the following way:
• Pin 1 – ground/shield
• Pin 2 – hot (+)
• Pin 3 – cold (–)
Fig.4.1
XLR input connector
+
-
030042
Gnd
1
2
3
BE169212.book Page 11 Tuesday, January 23, 2007 9:00 AM
