Installi
ng a
collimat
or
To insta
ll
an alter
nate
colli
mator
–
Step
Act
ion
1
Ensur
e
that
the instrument is powered off.
2
Using th
e provided
0.050
inch
hex
screwdri
ver, open the collimator hatch located
on the side of the instrument nose. Do not
allow debris to get inside the hatch area.
3
Using a th
umbnail on the lip of the curren
tly
installed
collimator, slide it out. It may be
tight.
4
Line up th
e new collimator with the groove
inside the hatch and slide it in until it clicks.
Again, do not allow debris inside.
5
Securely
close the hatch
and scr
ew
it shut.
