Bruker S1 TITAN - TRACER 5 Collimators and Filters

S1 TI
TAN, T
RACER
5, and CTX
User Manual
030.0112.04.0
10 of 67
1.2. T
RACER
5 Collimators and Filters
Descripti
on
The T
RACER
5 has ad
ditional, interchangeable features
–
 Filters.
 Collim
ators, stamped with either an 8 or 3.
They are applied as an assembly: a filter is inserted into the filter holder, which is attached to the
collimator with a screw.
Black filt
er holder Assembly Collimators
Filter t
ypes
Optional:
Five different filters and holders are available for the T
RACER
5. The h
ol
ders are ma
rked
in different colors to indicate filter type as per the chart below.
Filter
Name on
Screen
Holde
r Color
Ti 25µ
m
Blue
Blue
Cu 200µ
m:Ti 25µm:Al 300µm
Black
Black
Al 76µ
m
Orange
Orange
C 60µm:F 190µm
Teflon
White
No filter
None
Beige
Collimato
rs
The collima
tor determines the size of the spot on the sample to be tested.
For m
ost applications,
8mm spot
size is best. The 3mm spot size collimator reduces the focal point size and, therefore,
the analyzed area. For safety reasons, a collimator must be installed at all times.
If a collima
tor is…
Then
Installed
The size is disp
layed in the status bar and recorded in the data file.
Not install
ed
The instru
ment is prevented from entering the armed state and will not
produc
e X-rays.
