Scope of supply
l Weather-controlled heating circuit regulator for heating systems
l 3 screws 3,5 x 35 mm and 3 plugs 6 mm for wall installation.
l 6 strain relief clips with 12 screws, replacement fuse 2TA
l ModvlvS Logico Installation and operating instructions
Optionally contained depending on design/order:
l External relay for V1 / V2: 0-10V relay 1W / 6A (77502)
Hydraulic Variants
The following illustrations should be regarded only as schematic representations of the respective hydraulic systems
and do not claim to be complete. Under no circumstances should the controller replace any safety devices. Depend-
ing on the specific application, additional system and safety components such as check valves, non-return valves,
safety temperature limiters, scalding protectors, etc., may be required.
Logico ACS
Logico
6
