Bryant 350MAV - Page 38

TABLE 8—MODEL 350MAV ORIFICE SIZE AND MANIFOLD PRESSURE FOR CORRECT INPUT (CONTINUED)
FOR USE WITH 040 THROUGH 120 SIZE FURNACES ONLY
(TABULATED DATA BASED ON 20,000 BTUH PER BURNER, DERATED 2 PERCENT FOR EACH 1000 FT ABOVE SEA LEVEL)
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
U.S.A. Only
7001
to
8000
650 43 3.5 43 3.7 43 3.8 42 3.2 42 3.3
675 44 3.8 43 3.4 43 3.5 43 3.6 43 3.7
700 44 3.5 44 3.6 44 3.8 43 3.4 43 3.5
725 44 3.3 44 3.4 44 3.5 44 3.6 44 3.7
750 45 3.7 45 3.8 44 3.3 44 3.4 44 3.5
775 45 3.5 45 3.6 45 3.7 45 3.8 44 3.3
800 45 3.3 45 3.4 45 3.5 45 3.6 45 3.7
825 45 3.1 45 3.2 45 3.3 45 3.4 45 3.5
850 45 2.9 45 3.0 45 3.1 45 3.2 45 3.3
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
U.S.A. Only
Altitudes
8001
to
9000
625 43 3.5 43 3.6 43 3.8 42 3.2 42 3.3
650 44 3.7 43 3.4 43 3.5 43 3.6 43 3.7
675 44 3.5 44 3.6 44 3.7 44 3.8 43 3.4
700 44 3.2 44 3.3 44 3.4 44 3.6 44 3.7
725 45 3.6 45 3.8 44 3.2 44 3.3 44 3.4
750 45 3.4 45 3.5 45 3.6 45 3.8 44 3.2
775 45 3.2 45 3.3 45 3.4 45 3.5 45 3.6
800 45 3.0 45 3.1 45 3.2 45 3.3 45 3.4
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
Orifice
no.
Manifold
Pressure
U.S.A. Only
9001
to
10,000
600 43 3.5 43 3.6 43 3.7 42 3.2 42 3.3
625 44 3.7 44 3.8 43 3.5 43 3.6 43 3.7
650 44 3.4 44 3.5 44 3.7 44 3.8 43 3.4
675 44 3.8 44 3.3 44 3.4 44 3.5 44 3.6
700 45 3.6 45 3.7 45 3.8 44 3.3 44 3.4
725 45 3.3 45 3.4 45 3.6 45 3.7 45 3.8
750 45 3.1 45 3.2 45 3.3 45 3.4 45 3.5
775 45 2.9 45 3.0 45 3.1 45 3.2 45 3.3
*Orifice numbers shown in shading are factory installed.
—38—
