19
COOLING PERFORMANCE DATA
Model
Cooling Outdoor conditions (DB)
Indoor Conditions DB Indoor Conditions WB 77F(25C) 86F(30C) 95F(35C) 104F(40C) 113F(45C) 122F(50C)
09
(115V)
69.8F(21C) 59F(15C)
TC 7.43 7.83 9.74 8.38 6.11 5.11
SC 6.68 6.69 8.18 7.37 4.36 3.74
Input 0.35 0.54 0.81 0.8 0.75 0.75
75.2F(24C) 62.6F(17C)
TC 7.78 9.14 9.89 8.65 6.92 5.83
SC 3.58 8.11 6.27 5.52 4.85 4.29
Input 0.35 0.54 0.81 0.8 0.75 0.75
80.6F(27C) 66.2F(19C)
TC 8.21 9.22 10.41 9.27 7.32 6
SC 7.39 5.88 8.22 7.79 5.11 4.37
Input 0.35 0.75 0.82 0.81 0.75 0.75
89.6F(32C) 73.4F(23C)
TC 8.41 9.72 11.59 10.22 8.82 7.51
SC 3.68 5.76 6.9 6.2 5.55 5
Input 0.36 0.56 0.83 0.82 0.76 0.77
12
(115V)
69.8F(21C) 59F(15C)
TC 8.21 11.75 11.42 9 7.85 6.68
SC 7.06 9.05 8.68 7.38 6.42 5.58
Input 0.38 0.8 1.04 0.87 0.82 0.81
75.2F(24C) 62.6F(17C)
TC 8.42 11.84 12.01 9.35 8.32 7.34
SC 7.28 8.69 8.66 7.62 6.53 5.81
Input 0.57 0.94 1.25 1.27 0.98 0.94
80.6F(27C) 66.2F(19C)
TC 8.81 11.95 12.23 9.69 8.87 7.95
SC 7.49 8.32 8.63 7.85 6.64 6.04
Input 0.39 0.75 1.06 0.89 0.85 0.82
89.6F(32C) 73.4F(23C)
TC 9.01 12.15 12.43 9.89 9.07 8.15
SC 7.7 8.53 8.84 8.06 6.85 6.25
Input 0.4 0.97 1.3 1.34 0.92 0.85
09
(208-230V)
69.8F(21C) 59F(15C)
TC 7.41 7.82 9.73 8.34 6.12 5.1
SC 6.64 6.69 8.18 7.37 4.36 3.74
Input 0.35 0.54 0.81 0.8 0.75 0.75
75.2F(24C) 62.6F(17C)
TC 7.76 9.16 9.89 8.62 6.92 5.83
SC 3.58 8.11 6.27 5.52 4.85 4.29
Input 0.35 0.54 0.81 0.8 0.75 0.75
80.6F(27C) 66.2F(19C)
TC 8.21 9.22 10.41 9.27 7.32 6
SC 7.39 5.88 8.22 7.79 5.11 4.37
Input 0.35 0.75 0.82 0.81 0.75 0.75
89.6F(32C) 73.4F(23C)
TC 8.41 9.72 11.59 10.22 8.82 7.51
SC 3.68 5.76 6.9 6.2 5.55 5
Input 0.36 0.56 0.83 0.82 0.76 0.77
12
(208-230V)
69.8F(21C) 59F(15C)
TC 8.21 11.75 11.42 9 7.85 6.68
SC 7.06 9.05 8.68 7.38 6.42 5.58
Input 0.38 0.8 1.04 0.87 0.82 0.81
75.2F(24C) 62.6F(17C)
TC 8.42 11.84 12.01 9.35 8.32 7.34
SC 7.28 8.69 8.66 7.62 6.53 5.81
Input 0.57 0.94 1.25 1.27 0.98 0.94
80.6F(27C) 66.2F(19C)
TC 8.81 11.95 12.23 9.69 8.87 7.95
SC 7.49 8.32 8.63 7.85 6.64 6.04
Input 0.39 0.75 1.06 0.89 0.85 0.82
89.6F(32C) 73.4F(23C)
TC 9.01 12.15 12.43 9.89 9.07 8.15
SC 7.7 8.53 8.84 8.06 6.85 6.25
Input 0.4 0.97 1.3 1.34 0.92 0.85
18
(208-230V)
69.8F(21C) 59F(15C)
TC 12.58 15.24 16.25 11.04 8.32 6.78
SC 8.34 10.3 10.6 7.93 6.18 5.16
Input 0.58 0.93 1.53 1.2 1.42 1.32
75.2F(24C) 62.6F(17C)
TC 13.48 16.41 16.66 12.3 9.43 7.74
SC 8.85 10.94 11.35 8.62 6.87 5.91
Input 0.57 0.93 1.56 1.22 1.45 1.35
80.6F(27C) 66.2F(19C)
TC 14.43 18.04 18.37 13.35 9.97 7.96
SC 9.59 11.95 12.37 9.28 7.23 6.02
Input 0.57 0.94 1.59 1.24 1.48 1.38
89.6F(32C) 73.4F(23C)
TC 14.7 19.03 20.18 15.36 12.02 9.97
SC 9.08 11.72 12.5 9.69 7.85 6.89
Input 0.6 0.97 1.62 1.27 1.51 1.41
24
(208-230V)
69.8F(21C) 59F(15C)
TC 19.5 20.69 21.43 18.05 14.27 13.32
SC 15.15 15.61 15.49 14.23 10.03 8.78
Input 1.2 1.88 2.29 2.14 1.9 1.86
75.2F(24C) 62.6F(17C)
TC 20.01 21.21 22.31 18.51 15.08 13.3
SC 15.25 15.71 15.59 14.33 10.13 8.88
Input 1.2 1.87 2.3 2.21 2.14 1.92
80.6F(27C) 66.2F(19C)
TC 20.54 21.75 23.21 18.98 15.91 13.3
SC 15.35 15.81 15.69 14.43 10.23 8.98
Input 1.21 1.86 2.31 2.26 2.16 1.93
89.6F(32C) 73.4F(23C)
TC 20.61 22.94 24.4 21.84 19.17 16.66
SC 15.58 16.04 15.92 14.66 10.46 9.21
Input 1.22 1.87 2.34 2.33 2.32 1.96
30
(208-230V)
69.8F(21C) 59F(15C)
TC 27.33 27.43 27.51 22.77 18.29 17.32
SC 19.4 19.48 19.56 17.21 16.32 15.28
Input 2.28 3.29 3.63 3.11 2.35 2.25
75.2F(24C) 62.6F(17C)
TC 29.41 30.01 29.82 24.53 20.71 18.24
SC 19.95 20.47 20.07 17.73 17.24 16.29
Input 2.31 3.32 3.68 3.17 2.41 2.31
80.6F(27C) 66.2F(19C)
TC 31.57 32.68 32.21 26.37 23.2 19.21
SC 20.55 21.52 20.65 18.3 18.21 17.35
Input 2.35 3.35 3.74 3.23 2.47 2.38
89.6F(32C) 73.4F(23C)
TC 32.6 33.71 33.24 27.4 24.23 20.24
SC 20.9 21.87 21 18.65 18.56 17.7
Input 2.42 3.42 3.81 3.3 2.54 2.45
LEGEND
DB - Dry Bulb
WB - Wet Bulb
TC - Total Net Cooling Capacity (1000 Btu/hour)
SC - Sensible Capacity (1000 Btu/hour)
Input - Total power (kW)
