INDOOR FAN DRIVE DATA
TYPE
FAN RPM
Turns Open
012345
Std 1186 1132 1079 1029 970 916
Alt 1428 1374 1321 1267 1213 1158
ELECTRIC RESISTANCE HEATER DATA
HEATER kW*
HEATING
STAGES
% HEAT
PER STAGE
MAXIMUM
STAGES†
Unit Voltages
208 230 460
26 31 32 2 50/50 2
42 52 55 2 33/67 3
56 69 80 2 50/50 4
*Field-installed accessory only.
†Maximum number of stages using accessory outdoor-air thermostats.
NOTE: Heater kW is based on heater voltage of 240 v or 480 v. If power
distribution voltage to unit varies from rated heater voltage, heater kW
will vary accordingly.
STATIC PRESSURE LOSSES* (in. wg)
ACCESSORY/FIOP
UNIT
VOLTAGE
kW
CFM
3500 4000 4500 5000 5500 6000 6500 7000
Electric
Heaters
208/230-3-60
26/31 .04 .05 .06 .07 .08 .09 .11 .12
42/52 .05 .06 .07 .08 .10 .12 .14 .16
56/69 .06 .07 .08 .10 .12 .15 .17 .20
460-3-60
32 .04 .05 .06 .07 .08 .09 .11 .12
55 .05 .06 .07 .08 .10 .12 .14 .16
80 .06 .07 .08 .10 .12 .15 .17 .20
Economizer All — .02 .03 .04 .05 .06 .07 .08 .09
FIOP — Factory-Installed Option
*Static pressure losses must be added to external static pressure before entering Air Delivery table.
ELECTRICAL DATA
V-PH-HZ
VOLTAGE
RANGE
COMPRESSOR
(each)
OUTDOOR
FAN
MOTOR
INDOOR
FAN
MOTOR
ELECTRIC
HEAT
POWER SUPPLY*
Min Max RLA LRA Qty FLA Hp FLA kW† FLA MCA MOCP
208/230-3-60 187 254 31.3 137 2 7.7 3.0 10.5
— — 97/ 97 125/125
26/31 72/ 82 186/199 200/200
42/52 117/135 243/231 250/250
56/69 156/180 252/276 300/300
460-3-60 414 508 15.7 62 2 3.3 3.0 4.8
— — 47 60
32 39 96 100
55 66 113 125
80 96 143 150
LEGEND
FLA — Full Load Amps
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
RLA — Rated Load Amps
*Fuse only.
†Heater capacity (kW) is based on heater voltage of 240 v or 480 v. If
power distribution voltage to unit varies from rated heater voltage,
heater kW will vary accordingly. Heaters are field-installed only.
11
