VFD Fuses
Table 15 details the fuse requirement for the VFD installed in
580J/558J, 548J/549J and 581J/551J units. Table 16 details the
fuse requirement for the VFD installed in 524J units. Check the
control wiring diagram label on the specific unit in use for the
fuse location.
Table 15 — VFD Fuse Requirements, 558J/580J, 548J, 551J/581J, and 549J Units
UNIT HP VOLTAGE
VFD
(ACS320/ACH550/
ACH580)
MOTOR STANDARDIZED FUSE FUSE P/N
HARNESS
WIRE
GAUGE
a
558J/580J*07-14
548J*07-12
551J/581J*07-12
549J*07-09
1.7
208/230 HK30WA523 HD56FR233 30A - CLASS CC KTK HY10KB095 14
460 HK30WA530 HD56FR463 15A - CLASS CC KTK HY10KB092 14
575 HK30WA360 HD56FR579 10A - CLASS CC KTK HY10KB090 14
2.4
208/230 HK30WA523 HD56FE653 30A - CLASS CC KTK HY10KB095 14
460 HK30WA530 HD56FE653 15A - CLASS CC KTK HY10KB092 14
575
HK30WA360 (550)
HK30WB340 (580)
HD56FE577 10A - CLASS CC KTK HY10KB090 14
2.9
208/230 HK30WA523 HD58FE654 30A - CLASS CC KTK HY10KB095 14
460 HK30WA530 HD58FE654 15A - CLASS CC KTK HY10KB092 14
3.7
208/230 HK30WA523
HD60FE656,
HD58FR236
30A - CLASS CC KTK HY10KB095 14
460 HK30WA534
HD60FE656,
HD58FR236
20A - CLASS CC KTK HY10KB093 14
575
HK30WA361(550)
HK30WB341(580)
HD58FE577 10A - CLASS CC KTK HY10KB090 14
4.9
208/230 HK30WA523 HD60FK658 30A - CLASS CC KTK HY10KB095 14
460 HK30WA532 HD60FK658 30A - CLASS CC KTK HY10KB095 14
575 HK30WA362
HD60FE576,
HD60FL576
10A - CLASS CC KTK HY10KB090 14
558J/580J*16
548J*14
551J/581J*14
549J*12
2.9
208/230 HK30WA523 HD58FE654 30A - CLASS CC KTK HY10KB300 14
460 HK30WA530 HD58FE654 15A - CLASS CC KTK HY10KB151 14
575
HK30WA360 (550)
HK30WB340 (580)
— 10A - CLASS CC KTK HY10KB101 14
3.7
208/230 HK30WA523
HD60FE656,
HD58FR236
30A - CLASS CC KTK HY10KB300 14
460 HK30WA534
HD60FE656,
HD58FR236
20A - CLASS CC KTK HY10KB200 14
575 HK30WA361 HD58FE577 10A - CLASS CC KTK HY10KB101 14
5
208/230 HK30WA524
HD60FK657,
HD60FK659
30A - CLASS CC KTK HY10KB300 14
460 HK30WA532
HD60FK657,
HD60FK659
30A - CLASS CC KTK HY10KB300 14
575
HK30WA362 (550)
HK30WB342 (580)
HD60FE576,
HD60FL576,
HD60FK577
15A - CLASS CC KTK HY10KB151 14
558J/580J*17-30
548J*17-24
551J/581J*17-28
2.9
208/230 HK30WA523 HD58FE654 30A - CLASS CC KTK HY10KB300 10
460 HK30WA530 HD58FE654 15A - CLASS CC KTK HY10KB151 12
575
HK30WA360 (550)
HK30WB340 (580)
— 10A - CLASS CC KTK HY10KB101 12
3.7
208/230 HK30WA523 HD58FR236 30A - CLASS CC KTK HY10KB300 10
460 HK30WA534 HD60FE656 20A - CLASS CC KTK HY10KB200 12
575 HK30WA361 HD58FE577 10A - CLASS CC KTK HY10KB101 12
4.9
208/230 HK30WA523 HD60FK658 30A - CLASS CC KTK HY10KB300 10
460 HK30WA532 HD60FK658 30A - CLASS CC KTK HY10KB300 12
575
HK30WA362 (550)
HK30WB342 (580)
HD60FE576,
HD60FL576
15A - CLASS CC KTK HY10KB151 12
5
208/230 HK30WA524
HD60FK657,
HD60FK659
60 - CLASS J, JKS HY10JK060 8
460 HK30WA532
HD60FK657,
HD60FK659
30A - CLASS CC KTK HY10KB300 12
575
HK30WA362 (550)
HK30WB342 (580)
HD60FE576,
HD60FL576,
HD60FK577
15A - CLASS CC KTK HY10KB151 12
7.5
208/230 HK30WA524 HD62FK654 60 - CLASS J, JKS HY10JK060 8
460 HK30WA532 HD62FK654 30A - CLASS CC KTK HY10KB300 12
575
HK30WA362 (550)
HK30WB342 (580)
HD62FL576 15A - CLASS CC KTK HY10KB151 12
10
208/230 HK30WA525 HD64FK654 60 - CLASS J, JKS HY10JK060 8
460 HK30WA533 HD64FK654 30A - CLASS CC KTK HY10KB300 12
575
HK30WA363 (550)
HK30WB343 (580)
HD64FL576 15A - CLASS CC KTK HY10KB151 12
NOTE(S):
a. Harness wire gauge between control box and VFD.
