Control and Power Wiring Diagrams
See Fig. 32-38 for examples of typical unit wiring diagrams. For
details pertaining to a specific unit, see the control and power wir-
ing diagram labels on the unit.
Table 16 — VFD Fuse Requirements, 524J Units
UNIT HP VOLTAGE
VFD
(ACS320/ACH550/
ACH580)
MOTOR STANDARDIZED FUSE FUSE P/N
HARNESS
WIRE
GAUGE
a
524J
1.7
208/230 HK30WA523 HD56FR233 30A - CLASS CC KTK HY10KB300 10
460 HK30WA530 HD56FR463 15A - CLASS CC KTK HY10KB151 12
575
HK30WA360 (550)
HK30WB340 (580)
HD56FR579 10A - CLASS CC KTK HY10KB101 14
2.4
208/230 HK30WA523 HD56FE653 30A - CLASS CC KTK HY10KB300 10
460 HK30WA530 HD56FE653 15A - CLASS CC KTK HY10KB151 12
575
HK30WA360 (550)
HK30WB340 (580)
HD56FE577 10A - CLASS CC KTK HY10KB101 14
2.9
208/230 HK30WA523 HD58FE654 30A - CLASS CC KTK HY10KB300 10
460 HK30WA530 HD58FE654 30A - CLASS CC KTK HY10KB300 10
3.7
208/230 HK30WA523 HD58FR236 30A - CLASS CC KTK HY10KB300 10
208/230 HK30WA523 HD60FE656 30A - CLASS CC KTK HY10KB300 10
460 HK30WA534 HD58FR236 20A - CLASS CC KTK HY10KB200 12
460 HK30WA534 HD60FE656 20A - CLASS CC KTK HY10KB200 12
575
HK30WA361 (550)
HK30WB341 (580)
HD58FE577 10A - CLASS CC KTK HY10KB101 14
5
208/230 HK30WA524 HD60FK659 30A - CLASS CC KTK HY10KB300 10
460 HK30WA532 HD60FK659 30A - CLASS CC KTK HY10KB300 10
575
HK30WA362 (550)
HK30WB342 (580)
HD60FK577 15A - CLASS CC KTK HY10KB151 12
7.5
208/230 HK30WA523 HD62FK654 60A - CLASS J HY10JK060 8
460 HK30WA532 HD62FK654 30A - CLASS CC KTK HY10KB300 10
575
HK30WA362 (550)
HK30WB342 (580)
HD62FL576 15A - CLASS CC KTK HY10KB151 12
10
208/230 HK30WA525 HD64FK654 60A - CLASS J HY10JK060 8
460 HK30WA533 HD64FK654 30A - CLASS CC KTK HY10KB300 10
575
HK30WA363 (550)
HK30WB343 (580)
HD64FL576 15A - CLASS CC KTK HY10KB151 12
NOTE(S):
a. Harness wire gauge between control box and VFD.
