VFD PARAMETERS
• Table 18 — ACS320 VFD common parameters for
580J/558J, 548J, 581J/551J and 549J units with electro-
mechanical controls
• Table 19 — ACS320 Parameters for 580J/558J, 548J,
581J/551J and 549J units with electromechanical controls
• Table 20 — ACS320 VFD common parameters for 524J
units with electromechanical controls
• Table 21 — ACS320 Parameters for 524J units with
electromechanical controls
• Table 22 — ACH550/580 VFD common parameters for
580J/558J, 548J, 581J/551J and 549J units with electrome-
chanical controls
• Table 23 — ACH550/580 Parameters for 580J/558J, 548J,
581J/551J and 549J units with electromechanical controls
• Table 24 — ACH550/580 VFD parameters — 524J Unit
VFD parameters for units with VFD fan speed relay board
— 524J*07-30A and 524J*07-25H
Table 18 — ACS320 VFD Common Parameters for 580J/581J, 551J/558J, 548J and 549J Units
with Electromechanical Controls
PARAMETERS DESCRIPTION SETTING ACS320
9802 COMM PROT Sel Not Selected
9907 Motor Nominal Frequency 60Hz
1001 EXT1 Commands —
1102 EXT1/EXT2 Sel —
1103 REF 1 Select —
1201 Const Speed Sel DI 2,3
1202 Const Speed 1 40Hz
1203 Const Speed 2 60Hz
1204 Const Speed 3 60Hz
1205 Const Speed 4 —
1401 Relay Output 1 (16) FLT/ALARM
1403 Relay Output 3 Not Selected
1501 AO1 Content Sel —
1601 Run Enable —
1608 N/A —
1611 Parameter View 3
2007 Minimum Frequency 0.0 HZ
2008 Maximum Frequency 60HZ
2101 Start FCN (1) Auto
2102 Stop FCN (1) Coast
2201 ACCEL/DECEL (0) Not Sel
2202 ACCEL 30s
2203 DECEL 30s
2603 IR COMP Volt 0 volts
2606 Switching Freq 4 HZ
3102 Trial Time 300.0s
3103 Delay Time 6.0s
3104 AR Overcurrent (1) Enabled
5101 FBA Type —
5201 Station ID —
5202 Baud Rate —
5203 Parity —
5301 EFB Protocol ID —
5302 EFB Station ID —
5303 EFB Baud Rate —
5304 EFB Parity —
5305 EFB CTRL Profile —
LEGEND
— = HVAC Default, field does not require change.
