39
Table 22 — ACH550/580 VFD Common Parameters for 558J/580J and 551J/581J Units with Electromechanical Controls
PARAMETERS ACH550 / 580 DESCRIPTION SETTING ACH550 | ACH580
9802 / 58.01 COMM PROT Sel —
9907 / 99.08 Motor Nominal Frequency 60Hz
1001 / 20.01 EXT1 Commands —
1102 / 19.11 EXT1/EXT2 Sel —
1103 / 28.11 REF 1 Select —
1201 / 28.22 Const Speed Sel DI2,3 | DI2
1201 / 28.23 Const Speed Sel DI2,3 | DI3
1202 / 28.26 Const Speed 1 40Hz
1203 / 28.27 Const Speed 2 60Hz
1204 / 28.28 Const Speed 3 60Hz
1205 / 28.29 Const Speed 4 —
1401 / 10.24 Relay Output 1 —
1403 / 10.30 Relay Output 3 16 FLT/Alarm | FLT/ (14) Fault
1501 / 13.12 AO1 Content Sel —
1601 / 20.40 Run Enable —
2007 / 30.13 Minimum Frequency 0Hz
2008 / 30.14 Maximum Frequency 60Hz
2101 / 21.19 Start FCN Auto | Automatic
2102 / 21.03 Stop FCN Ramp
2201 / 28.71 ACCEL/DECEL Not Sel | 0
2202 / 28.72 ACCEL 30s
2203 / 28.73 DECEL 30s
2606 / 97.01 Switching Freq 4kHz
5101 / 51.01 FBA Type —
5201 / 58.03 Station ID —
5202 / 58.04 Baud Rate —
5203 / 58.05 Parity —
5301 / 58.25 EFB Protocol ID —
5302 / 58.03 EFB Station ID —
5303 / 58.04 EFB Baud Rate —
5304 / 58.05 EFB Parity —
5305 / 58.25 EFB CTRL Profile —
