Bryant 548J - Page 42

42
Table 24 — ACH550/580 VFD Parameters —
524J Unit VFD Parameters for Units with VFD Fan Speed Relay Board —
524J*07-30A and 524J*07-25H
550/580 VFD PART
NUMBER
550/580 ABB PART
NUMBER
DESC
MOTOR PART
NUMBER
550/580 VOLT
9905 / 99.07
550 / 580 NOM
AMPS
9906 / 99.06
550 / 580
MOTOR NOM
FREQ 9907 /
99.08
550 / 580
NOM RPM
9908 / 99.09
550 / 580
NOM HP
9909 / 99.10
HK30WA353 /
HK30WB305
ACH550-UH-017A-2 /
ACH580-01-017A-2
2.4 HP 230V HD56FE653 230 7.9 60 Hz 1725 2.4
HK30WA357 /
HK30WB321
ACH550-UH-08A8-4 /
ACH580-01-07A6-4
2.4 HP 460V HD56FE653 460 4.0 60 Hz 1725 2.4
HK30WA361 /
HK30WB341
ACH550-UH-06A1-6 /
ACH580-01-06A1-6
2.4 HP 575V HD56FE577 575 3.4 60 Hz 1725 2.4
HK30WA353 /
HK30WB305
ACH550-UH-017A-2 /
ACH580-01-017A-2
2.9 HP 230V HD58FE654 230 9.2 60 Hz 1725 2.9
HK30WA357 /
HK30WB321
ACH550-UH-08A8-4 /
ACH580-01-07A6-4
2.9 HP 460V HD58FE654 460 4.0 60 Hz 1725 2.9
HK30WA353 /
HK30WB305
ACH550-UH-017A-2 /
ACH580-01-017A-2
3.7 HP 230V HD60FE656 230 11.2 60 Hz 1725 3.7
HK30WA357 /
HK30WB321
ACH550-UH-08A8-4 /
ACH580-01-07A6-4
3.7 HP 460V HD60FE656 460 5.6 60 Hz 1725 3.7
HK30WA361 /
HK30WB341
ACH550-UH-06A1-6 /
ACH580-01-06A1-6
3.7 HP 575V HD58FE577 575 4.2 60 Hz 1725 3.7
HK30WA354 /
HK30WB306
ACH550-UH-024A-2 /
ACH580-01-024A-2
5.0 HP 230V HD60FK653 230 15.3 60 Hz 1745 5.0
HK30WA358 /
HK30WB322
ACH550-UH-012A-4 /
ACH580-01-012A-4
5.0 HP 460V HD60FK653 460 6.4 60 Hz 1745 5.0
HK30WA362 /
HK30WB342
ACH550-UH-09A0-6 /
ACH580-01-09A0-6
5.0 HP 575V HD60FK575 575 5.4 60 Hz 1760 5.0
HK30WA354 /
HK30WB306
ACH550-UH-024A-2 /
ACH580-01-024A-2
7.5 HP 230V HD62FK652 230 22.4 60 Hz 1760 7.5
HK30WA358 /
HK30WB322
ACH550-UH-012A-4 /
ACH580-01-012A-4
7.5 HP 460V HD62FK652 460 9.7 60 Hz 1760 7.5
HK30WA362 /
HK30WB342
ACH550-UH-09A0-6 /
ACH580-01-09A0-6
7.5 HP 575V HD62FK576 575 9.0 60 Hz 1750 7.5
HK30WA355 /
HK30WB307
ACH550-UH-031A-2 /
ACH580-01-031A-2
10.0 HP 230V HD64FK654 230 30.8 60 Hz 1760 10.0
HK30WA359 /
HK30WB324
ACH550-UH-015A-4 /
ACH580-01-023A-4
10.0 HP / 15
HP 460V
HD64FK654 460 15.4 60 Hz 1760 10.0
HK30WA363 /
HK30WB343
ACH550-UH-011A-6 /
ACH580-01-011A-6
10.0 HP 575V HD64FK575 575 11.0 60 Hz 1755 10.0
