116
PERFORMANCE DATA — 549B, 549C (cont)
ACCESSORY ELECTRIC HEATERS STATIC PRESSURE* (in. wg) — 549B036-072 AND 549C024-060
LEGEND
*The static pressure must be added to external static pressure. The sum and the indoor entering-air cfm
should be used in conjunction with the Fan Performance tables to determine indoor blower rpm and watts.
ACCESSORY ELECTRIC HEATERS STATIC PRESSURE* (in. wg) — 549B090-120
LEGEND
*The static pressure must be added to external static pressure. The sum and the indoor entering-air cfm
should be used in conjunction with the Fan Performance tables to determine indoor blower rpm and watts.
ACCESSORY/FIOP ECONOMIZER STATIC PRESSURE* (in. wg) — 549B036-072 AND 549C024-060
LEGEND
*The static pressure must be added to external static pressure. The sum and the indoor entering-air cfm
should be used in conjunction with the Fan Performance tables to determine indoor blower rpm and watts.
ACCESSORY/FIOP ECONOMIZER STATIC PRESSURE* (in. wg) — 549B090-120
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The sum and the evaporator
entering-air cfm should then be used in conjunction with the Fan Performance tables to deter-
mine blower rpm and watts.
NOTE: The rooftop unit return air configuration determines the economizer configuration (verti-
cal or horizontal).
COMPONENT
CFM
600 900 1200 1400 1600 1800 2000 2200 2400 2600
1 Heater Module
0.03 0.05 0.07 0.09 0.09 0.10 0.11 0.11 0.12 0.13
2 Heater Modules
0.14 0.15 0.16 0.16 0.16 0.17 0.17 0.17 0.18 0.18
FIOP — Factory-Installed Option
COMPONENT
CFM
2250 2500 3000 3500 4000 4500 5000 5500 6000 6250
1 Heater Module 0.02 0.03 0.05 0.07 0.08 0.10 0.12 0.14 0.16 0.17
2 Heater Modules 0.03 0.05 0.07 0.09 0.12 0.14 0.16 0.19 0.21 0.20
FIOP — Factory-Installed Option
COMPONENT
CFM
1250 1500 1750 2000 2250 2500 2750 3000
Vertical EconoMi$er2 and EconoMi$erIV 0.045 0.065 0.08 0.12 0.145 0.175 0.22 0.255
Horizontal EconoMi$er2 and EconoMi$erIV — — 0.1 0.125 0.15 0.18 0.225 0.275
FIOP — Factory-Installed Option
COMPONENT
CFM
2250 2500 2750 3000 3250 3500 3750 4000 4250 4500 4750 5000 5250 6250
Vertical EconoMi$er2 and EconoMi$erIV 0.06 0.075 0.09 0.115 0.13 0.15 0.17 0.195 0.22 0.25 0.285 0.325 0.36 —
Horizontal EconoMi$er2 and EconoMi$erIV — 0.1 0.125 0.15 0.18 0.21 0.25 0.275 0.3 0.34 0.388 — — —
549B, 549C
