Bryant 549C - Typical Wiring Schematics

156
TYPICAL WIRING SCHEMATIC — 542J (cont)
4
3
5
2
8
6
7
1
10
11
9
12
PINK
BLACK
BLUE
NOTE 1
NOTE 2
RUN
500 OHM
RESISTOR
50HJ540573
ACTUATOR
ASSEMBLY
RED
WHITE
ECONOMISER2 PLUG
DIRECT DRIVE
ACTUATOR
OAT
LEGEND
OAT — Outdoor Air Temperature Sensor
NOTES:
1. Switch on actuator must be in run position for economizer to operate.
2. 50HJ540573 actuator consists of the 50HJ540567 actuator and a harness with 500-ohm resistor.
EconoMi$er2 Wiring — 542J150,180
Non-Fused Disconnect (Optional) — 542J150,180
NOTES:
1. If the Non-Fused Disconnect Service Option is ordered for size 150 and 180 units, the Non-Fused Disconnect will be factory-installed.
2. The Disconnect takes the place of TB-1 as shown on the unit wiring diagram label and the component arrangement label.
a50-8058
a48-6005
542J
