ELECTRICAL DATA — 549B
549B036-120 STANDARD MOTOR UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
See Legend on page 114.
UNIT
549B
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE
COMPRESSOR OFM IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
036
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— —/— 25.6/ 25.6 30/ 30** 25/ 25 101/101
3.3/ 4.4 15.9/18.3 45.5/ 48.5 50/ 50** 43/ 46 117/120
4.9/ 6.5 23.6/27.1 55.1/ 59.5 60/ 60** 52/ 56 125/128
6.5/ 8.7 31.3/36.3 64.7/ 71.0 70/ 80 61/ 67 133/138
7.9/10.5 38.0/43.8 73.1/ 80.4 80/ 90 69/ 75 139/145
9.8/13.0 47.1/54.2 84.5/ 93.4 90/100 79/ 87 148/155††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 18.5/ 18.5 20/20** 18/ 18 90/ 90
3.3/ 4.4 9.2/10.6 30.0/ 31.7 30/35** 29/ 30 99/101
4.9/ 6.5 13.6/15.6 35.5/ 38.0 40/40** 34/ 36 104/106
6.5/ 8.7 18.0/20.9 41.0/ 44.6 45/45** 39/ 42 108/111
7.9/10.5 21.9/25.3 45.9/ 50.1 50/60** 43/ 47 112/116
12.0/16.0 33.3/38.5 60.1/ 66.6 70/70 57/ 63 124/129
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 9.0 15** 9 46
6.0 7.2 18.0 20** 17 53
8.8 10.6 22.2 25** 21 57
11.5 13.8 26.2 30** 25 60
14.0 16.8 30.0 30** 28 63
048
(4 Tons)
208/230-1-60 187 254 18.3 109.0 0.7 4.9
—/— —/— 28.5/ 28.5 30/ 30** 27/ 27 122/122
3.3/ 4.4 15.9/18.3 48.4/ 51.4 50/ 60** 46/ 49 138/141
6.5/ 8.7 31.3/36.3 67.6/ 73.9 70/ 80 63/ 69 154/159
9.8/13.0 47.1/54.2 87.4/ 96.2 90/100 82/ 90 169/176††
13.1/17.4 63.0/72.5 107.2/119.1 110/125 100/111 185/195††
15.8/21.0 76.0/87.5 123.5/137.9 125/150 115/128 198/210††
208/230-3-60 187 254 12.4 88.0 0.7 4.9
—/— —/— 21.1/21.1 25/25** 21/ 21 101/101
4.9/ 6.5 13.6/15.6 38.1/40.6 40/45** 36/ 39 115/117
6.5/ 8.7 18.0/20.9 43.6/47.2 45/50** 41/ 45 119/122
12.0/16.0 33.3/38.5 62.7/69.2 70/70 59/ 65 135/140
15.8/21.0 43.9/50.5 76.0/84.2 80/90 71/ 79 145/152
460-3-60 414 508 6.4 44.0 0.4 2.2
— — 10.6 15** 10 51
6.0 7.2 19.6 20** 19 58
11.5 13.8 27.9 30** 26 65
14.0 16.8 31.6 35** 30 68
23.0 27.7 45.2 50** 42 79
060
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— — 40.4/ 40.4 45/ 45** 39/ 39 188/188
4.9/ 6.5 23.6/27.1 69.9/ 74.2 70/ 80 66/ 70 211/215
6.5/ 8.7 31.3/36.3 79.5/ 85.7 80/ 90 75/ 81 219/224††
9.8/16.0 47.1/54.2 99.2/108.1 100/110 93/102 235/242††
13.1/17.4 63.0/72.5 119.1/131.0 125/150 112/123 251/260††
15.8/21.0 76.0/87.5 135.4/149.7 150/150 127/140 264/275††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 28.9/ 28.9 30/ 30** 28/ 28 168/168
4.9/ 6.5 13.6/15.6 45.9/ 48.4 50/ 50** 44/ 46 181/183
7.9/10.5 21.9/25.3 56.3/ 60.6 60/ 70 53/ 57 190/193
12.0/16.0 33.3/38.5 70.6/ 77.1 80/ 80 67/ 73 201/208
15.8/21.0 43.9/50.5 83.8/ 92.1 90/100 79/ 86 212/218††
19.9/26.5 55.2/63.8 97.9/108.7 100/110 92/102 223/232††
460-3-60 414 508 9.0 62.0 0.8 2.6
— — 13.9 15** 14 92
6.0 7.2 22.9 25** 22 100
11.5 13.8 31.2 35** 29 106
14.0 16.8 34.9 35** 33 109
23.0 27.7 48.5 50** 45 120
25.5 30.7 51.5 60** 48 123
072
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—/— —/— 32.8/ 32.8 35/ 35** 32/ 32 200/200
4.9/ 6.5 13.6/15.6 49.8/ 52.3 50/ 60** 47/ 50 214/216
7.9/10.5 21.9/25.3 60.2/ 64.5 70/ 70 57/ 61 222/225
12.0/16.0 33.3/38.5 74.5/ 81.0 80/ 90 70/ 76 233/239
15.8/21.0 43.9/50.5 87.7/ 96.0 90/100 82/ 90 244/251††
19.9/26.5 55.2/63.8 101.8/112.6 110/125 95/105 255/264††
460-3-60 414 508 9.6 70.0 0.6 2.6
— — 15.2 20** 15 92
6.0 7.2 24.2 25** 23 99
11.5 13.8 32.5 35** 31 106
14.0 16.8 36.2 40** 34 109
23.0 27.7 49.8 50** 47 120
25.5 30.7 53.6 60** 50 123
