ELECTRICAL DATA — 549B (cont)
549B036-120 — STANDARD MOTOR UNITS WITH ELECTRICAL CONVENIENCE OUTLET
See Legend on page 122.
UNIT
549B
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE
COMPRESSOR OFM IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
036
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— — 30.4/ 30.4 35/ 35** 30/ 30 106/106
3.3/ 4.4 15.9/18.3 50.3/ 53.3 60/ 60** 49/ 51 122/124
4.9/ 6.5 23.6/27.1 59.9/ 64.3 60/ 70 58/ 62 130/133
6.5/ 8.7 31.3/36.3 69.5/ 75.8 70/ 80 66/ 72 137/142
7.9/10.5 38.0/43.8 77.9/ 85.2 80/ 90 74/ 81 144/150††
9.8/13.0 47.1/54.2 89.3/ 98.2 90/100 85/ 93 153/160††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 23.3/ 23.3 25/ 25** 24/ 24 95/ 95
3.3/ 4.4 9.2/10.6 34.8/ 36.5 35/ 40** 34/ 36 104/106
4.9/ 6.5 13.6/15.6 40.3/ 42.8 45/ 45** 39/ 42 109/111
6.5/ 8.7 18.0/20.9 45.8/ 49.4 50/ 50** 45/ 48 113/116
7.9/10.5 21.9/25.3 50.7/ 54.9 60/ 60** 49/ 53 117/120
12.0/16.0 33.3/38.5 64.9/ 71.4 70/ 80 62/ 68 128/134
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 11.2 15** 11 48
6.0 7.2 20.2 25** 20 55
8.8 10.6 24.4 25** 24 59
11.5 13.8 28.4 30** 27 62
14.0 16.8 32.2 35** 31 65
048
(4 Tons)
208/230-1-60 187 254 18.3 109.0 0.7 4.9
—/— —/— 33.3/ 33.0 35/ 35** 33/ 33 127/127
3.3/ 4.4 15.9/18.3 53.2/ 56.2 60/ 60 51/ 54 143/145
6.5/ 8.7 31.3/36.3 72.4/ 78.7 80/ 80 69/ 75 158/163††
9.8/13.0 47.1/54.2 92.2/101.0 100/110 87/ 95 174/181††
13.1/17.4 63.0/72.5 112.0/123.9 125/125 105/116 190/200††
15.8/21.0 76.0/87.5 128.3/142.7 150/150 120/134 203/215††
208/230-3-60 187 254 12.4 88.0 0.7 4.9
—/— —/— 25.9/ 25.9 30/ 30** 26/ 26 106/106
4.9/ 6.5 13.6/15.6 42.9/ 45.4 45/ 50** 42/ 44 120/122
6.5/ 8.7 18.0/20.9 48.4/ 52.0 50/ 60** 47/ 50 124/127
12.0/16.0 33.3/38.5 67.5/ 74.0 70/ 80 65/ 71 139/145
15.8/21.0 43.9/50.5 80.8/ 89.0 90/ 90 77/ 84 150/157††
460-3-60 414 508 6.4 44.0 0.4 2.2
— — 12.8 15** 13 53
6.0 7.2 21.8 25** 21 60
11.5 13.8 30.0 35** 29 67
14.0 16.8 33.8 35** 32 70
23.0 27.7 47.4 50** 45 81
060
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— — 45.2/ 45.2 50/ 50** 45/ 45 193/193
4.9/ 6.5 23.6/27.1 74.7/ 79.0 80/ 80 72/ 76 216/220††
6.5/ 8.7 31.3/36.3 84.3/ 90.5 90/100 81/ 86 224/229††
9.8/16.0 47.1/54.2 104.0/112.9 110/125 99/107 240/247††
13.1/17.4 63.0/72.5 123.9/135.8 125/150 117/128 256/265††
15.8/21.0 76.0/87.5 140.2/154.5 150/175 132/145 269/280††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 33.7/ 33.7 35/ 35** 34/ 34 173/173
4.9/ 6.5 13.6/15.6 50.7/ 53.2 60/ 60** 49/ 52 186/188
7.9/10.5 21.9/25.3 61.1/ 65.4 70/ 70 59/ 63 194/198
12.0/16.0 33.3/38.5 75.4/ 81.9 80/ 90 72/ 78 206/211
15.8/21.0 43.9/50.5 88.6/ 96.9 90/100 84/ 92 216/223††
19.9/26.5 55.2/63.8 102.7/113.5 110/125 97/107 228/236††
460-3-60 414 508 9.0 62.0 0.8 2.6
— — 16.1 20** 16 95
6.0 7.2 25.1 30** 24 102
11.5 13.8 33.3 35** 32 108
14.0 16.8 37.1 40** 35 111
23.0 27.7 50.7 60** 48 122
25.5 30.7 53.7 60** 51 125
072
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—/— —/— 37.6/ 37.6 40/ 40** 37/ 37 205/205
4.9/ 6.5 13.6/15.6 54.6/ 57.1 60/ 60** 53/ 55 219/221
7.9/10.5 21.9/25.3 65.0/ 69.3 70/ 70 63/ 66 227/230
12.0/16.0 33.3/38.5 79.3/ 85.8 80/ 90 76/ 82 238/243††
15.8/21.0 43.9/50.5 92.5/100.8 100/110 88/ 95 249/255††
19.9/26.5 55.2/63.8 106.6/117.4 110/125 101/111 260/269††
460-3-60 414 508 9.6 70.0 0.6 2.6
— — 17.4 20** 17 99
6.0 7.2 26.4 30** 26 106
11.5 13.8 34.6 35** 33 113
14.0 16.8 38.4 40** 37 116
23.0 27.7 52.0 60** 49 127
25.5 30.7 55.8 60** 53 130
549B, 549C
