ELECTRICAL DATA — 549B (cont)
549B036-120 — HIGH-STATIC MOTOR UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
See Legend on page 124.
UNIT
549B
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE
COMPRESSOR OFM IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
036
(3 Tons)
208/230-3-60 187 254 10.3 77.0 0.7 5.8
—/— —/— 19.4/ 19.4 20/20 19/ 19 120/120
3.3/ 4.4 9.2/10.6 30.9/ 32.6 35/35 30/ 32 129/130
4.9/ 6.5 13.6/15.6 36.4/ 38.9 40/40 35/ 37 133/135
6.5/ 8.7 18.0/20.9 41.9/ 45.5 45/50 40/ 43 138/141
7.9/10.5 21.9/25.3 46.8/ 51.0 50/60 45/ 48 142/145
12.0/16.0 33.3/38.5 61.0/ 67.5 70/70 58/ 64 153/158
460-3-60 414 508 5.1 39.0 0.4 2.6
— — 9.4 15** 9 60
6.0 7.2 18.4 20** 18 68
8.8 10.6 22.6 25** 22 71
11.5 13.8 26.6 30** 25 74
14.0 16.8 30.4 35** 29 77
048
(4 Tons)
208/230-3-60 187 254 12.4 88.0 0.7 5.8
—/— —/— 22.0/ 22.0 25/ 25 22/ 22 131/131
4.9/ 6.5 13.6/15.6 39.0/ 41.5 40/ 45 37/ 40 144/146
6.5/ 8.7 18.0/20.9 44.5/ 48.1 45/ 50 42/ 46 149/152
12.0/16.0 33.3/38.5 63.6/ 70.1 70/ 80 60/ 66 164/169
15.8/21.0 43.9/50.5 76.9/ 85.1 80/ 90 72/ 80 175/181††
460-3-60 414 508 6.4 44.0 0.4 2.6
— — 11.0 15** 11 65
6.0 7.2 20.0 20** 19 73
11.5 13.8 28.3 30** 27 79
14.0 16.8 32.0 35** 30 82
23.0 27.7 45.6 50** 43 93
060
(5 Tons)
208/230-3-60 187 254 17.3 123.0 1.5 7.5
—/— —/— 30.6/ 30.6 35/ 35 30/ 30 187/187
4.9/ 6.5 13.6/15.6 47.6/ 50.1 50/ 60 46/ 48 200/202
7.9/10.5 21.9/25.3 58.0/ 62.3 60/ 70 55/ 59 209/212
12.0/16.0 33.3/38.5 72.3/ 78.8 80/ 80 69/ 75 220/225
15.8/21.0 43.9/50.5 85.5/ 93.8 90/100 81/ 88 231/237**
19.9/26.5 55.2/63.8 99.6/110.4 100/125 94/104 242/251**
460-3-60 414 508 8.4 70.0 0.8 3.4
— — 14.7 15** 14 102
6.0 7.2 23.7 25** 23 109
11.5 13.8 32.0 35** 30 116
14.0 16.8 35.7 40** 34 119
23.0 27.7 49.3 50** 46 130
25.5 30.7 52.3 60** 49 132
072
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 7.5
—/— —/— 34.5/ 34.5 35/ 35 34/ 34 219/219
4.9/ 6.5 13.6/15.6 51.5/ 54.0 60/ 60 49/ 52 233/235
7.9/10.5 21.9/25.3 61.9/ 66.2 70/ 70 59/ 63 241/244
12.0/16.0 33.3/38.5 76.2/ 82.7 80/ 90 72/ 78 252/258
15.8/21.0 43.9/50.5 89.4/ 97.7 90/100 84/ 92 263/270**
19.9/26.5 55.2/63.8 103.5/114.3 110/125 97/107 274/283**
460-3-60 414 508 9.6 70.0 0.6 3.4
— — 16.0 20** 16 107
6.0 7.2 25.0 25** 24 114
11.5 13.8 33.3 35** 32 120
14.0 16.8 37.0 40** 35 123
23.0 27.7 50.6 60** 47 134
25.5 30.7 54.4 60** 51 137
549B, 549C
