54
PERFORMANCE DATA — 548F (cont)
INDOOR-FAN MOTOR PERFORMANCE — 548F036-120 UNITS
LEGEND
BHP — Brake Horsepower
*Extensive motor and electrical testing on these units ensures that the full horse-
power range of the motors can be utilized with confidence. Using your fan
motors up to the horsepower ratings shown in this table will not result in nui-
sance tripping or premature motor failure. Unit warranty will not be affected.
†Single-phase/three-phase.
NOTES:
1. All indoor-fan motors 5 hp and larger meet the minimum efficiency require-
ments as established by the Energy Policy Act of 1992 (EPACT) effective
October 24, 1997.
2. High-static motor not available on single-phase units.
UNIT
548F
INDOOR-FAN
MOTOR
UNIT
VOLTAGE
MAXIMUM ACCEPTABLE
CONTINUOUS BHP*
MAXIMUM ACCEPTABLE
OPERATING WATTS
MAXIMUM
AMP DRAW
MOTOR
EFFICIENCY (%)
036
Standard
208/230
0.34 440
2.8
75
460 1.3
575 1.3
Alternate
208/230
1.00 1000
4.9
460 2.1
575 2.1
High Static
208/230
2.40 2120
6.0
460 3.0
575 3.0
048
Standard
208/230
0.75 850
3.5
75
460 1.8
575 1.8
Alternate
208/230
1.00 1000
4.9
460 2.1
575 2.1
High Static
208/230
2.40 2120
6.0
460 3.0
575 3.0
060
Standard
208/230
1.20 1340
5.9
74
460 3.2
575 3.2
Alternate
208/230
1.30/2.40† 2120
7.6/6.0†
460 3.0
575 3.0
High Static
208/230
2.90 2562
8.6
460 3.9
575 3.9
072
Standard
208/230
2.40 2120
6.0
84
460 3.0
575 3.0
High Static
208/230
2.90 2562
8.6
460 3.9
575 3.9
090
Standard,
Alternate
208/230
2.40 2120
6.0
80
460 3.0
575 3.0
High Static
208/230
3.70 3313
11.7
460 5.5
575 5.5
120
Standard
208/230
2.40 2120
6.0
80
460 3.0
575 3.0
Alternate
208/230
2.90 2615
8.6
460 3.9
575 3.9
High Static
208/230
5.25 4400
17.3
460 8.5
575 8.5
548F
