Bryant 574D----A - Performance Data - 574 D-A24; Cooling Performance (A24); Performance Data Legend and Notes

13
PERFORMANCE DATA 574D----A24
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES _F(_C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM/BF
EWB
_F
(_C)
Capacity M Btuh
Total
Sys
kW
Capacity M Btuh
Total
Sys
KW
Capacity M Btuh
Total
Sys
KW
Capacity M Btuh
Total
Sys
KW
Capacity M Btuh
Total
Sys
KW
Capacity M Btuh
Total
Sys
KW
Total Sens Total Sens Total Sens Total Sens Total Sens Total Sens
700/0.07
57
(13.8)
22.74 22.74 1.66 21.26 21.26 1.85 19.77 19.77 2.06 18.28 18.28 2.29 16.77 16.77 2.54 15.24 15.24 2.80
62
(16.6)
23.94 20.55 1.66 22.18 19.57 1.86 20.42 18.59 2.07 18.67 17.59 2.30 16.93 16.57 2.54 15.24 15.24 2.80
63*
(17.2)
24.48 17.00 1.67 22.68 16.12 1.86 20.88 15.23 2.07 19.08 14.35 2.30 17.27 13.46 2.54 15.45 12.56 2.81
67
(19.4)
26.34 17.55 1.67 24.42 16.65 1.86 22.49 15.76 2.07 20.57 14.86 2.30 18.64 13.97 2.55 16.70 13.07 2.82
72
(22.2)
28.95 14.51 1.67 26.85 13.70 1.87 24.76 12.88 2.08 22.66 12.07 2.31 20.56 11.25 2.56 18.45 10.43 2.83
800/0.09
57
(13.8)
23.78 23.78 1.68 22.21 22.21 1.87 20.64 20.64 2.08 19.06 19.06 2.31 17.46 17.46 2.56 15.85 15.85 2.82
62
(16.6)
24.57 22.03 1.68 22.75 20.99 1.87 20.94 19.93 2.08 19.15 18.83 2.31 17.46 17.46 2.56 15.85 15.85 2.82
63*
(17.2)
25.10 18.06 1.68 23.23 17.14 1.88 21.36 16.21 2.09 19.49 15.29 2.32 17.62 14.37 2.56 15.74 13.44 2.82
67
(19.4)
27.00 18.66 1.69 25.00 17.73 1.88 23.00 16.80 2.09 21.01 15.87 2.32 19.01 14.94 2.57 17.00 14.00 2.83
72
(22.2)
29.65 15.23 1.69 27.48 14.39 1.89 25.30 13.54 2.10 23.13 12.71 2.33 20.96 11.86 2.58 18.77 11.01 2.84
900/0.1
57
(13.8)
24.67 24.67 1.70 23.02 23.02 1.89 21.37 21.37 2.10 19.71 19.71 2.33 18.05 18.05 2.58 16.36 16.36 2.84
62
(16.6)
25.09 23.40 1.70 23.23 22.27 1.89 21.39 21.39 2.10 19.71 19.71 2.33 18.04 18.04 2.58 16.35 16.35 2.84
63*
(17.2)
25.60 19.06 1.70 23.66 18.11 1.89 21.74 17.15 2.10 19.81 16.20 2.33 17.89 15.24 2.58 15.96 14.27 2.84
67
(19.4)
27.52 19.73 1.70 25.45 18.76 1.90 23.40 17.80 2.11 21.34 16.83 2.34 19.29 15.87 2.59 17.23 14.89 2.85
72
(22.2)
30.21 15.91 1.71 27.97 15.04 1.90 25.72 14.18 2.11 23.50 13.31 2.35 21.26 12.45 2.60 19.02 11.58 2.86
See Legend and Notes on Page 19.
574D-- -- A
