PHYSICAL DATA
UNIT SIZE 24040 24060 30040 30060 36060 36090 42060 42090
NOMINAL COOLING CAP ACITY (ton) 2 2 2 --- 1 / 2 2 --- 1 / 2 3 3 3 --- 1 / 2 3 --- 1 / 2
NOMINAL HEATING INPUT (Btu/hr) 40,000 60,000 40,000 60,000 60,000 90,000 60,000 90,000
SHIPPING WEIGHT** lb.
SHIPPING WEIGHT** (kg)
311
141
311
141
316
143
316
143
326
148
326
148
420
191
420
191
COMPRESSORS
Quantity
Scroll
1
REFRIGERANT (R --- 410A)
Quantity lb.
Quantity (kg)
4.8
2.2
4.8
2.2
6.2
2.8
6.2
2.8
6.4
2.9
6.4
2.9
6.1
2.7
6.1
2.7
REFRIGERANT METERING DEVICE TXV
OUTDOOR COIL
Rows...Fins/in.
Face Area (sq ft)
1..21
10.2
1...21
10.2
1...21
11.9
1...21
11.9
1...21
15.4
1...21
15.4
1...21
13.6
1...21
13.6
OUTDOOR FAN
Nominal CFM
Diameter in.
Diameter (mm)
Motor Hp (Rpm)
2800
24
609.6
1/5 ( 810)
2800
24
609.6
1/5 ( 810)
3000
24
609.6
1/5 ( 810)
3000
24
609.6
1/5 ( 810)
3200
24
609.6
1/5 ( 810)
3200
24
609.6
1/5 ( 810)
3600
26
660.4
1/5 ( 810
3600
26
660.4
1/5 ( 810)
INDOOR COIL
Rows...Fins/in.
Face Area (sq ft)
2...17
3.7
2...17
3.7
3...17
3.7
3...17
3.7
3...17
3.7
3...17
3.7
3...17
4.7
3...17
4.7
INDOOR BLOWER
Nominal Cooling Airflow (Cfm)
Size in.
Size (mm.)
Motor HP (RPM)
800
10x10
254x254
1/2 ( 1050)
800
10x10
254x254
1/2 ( 1050)
1000
10x10
254x254
1/2 ( 1050)
1000
10x10
254x254
1/2 ( 1050)
1200
11x10
279.4x254
3/4 ( 1000)
1200
11x10
279.4x254
3/4 ( 1000)
1400
11x10
279.4x254
3/4 ( 1075)
1400
11x10
279.4x254
3/4 ( 1075)
FURNACE SECTION*
Burner Orifice No. (Qty...Dr ill Size)
Natural Gas Factory Installed
Propane Gas
2...44
2...55
2...38
2...53
2...44
2...55
2...38
2...53
2...38
2...53
3...38
3...53
2...38
2...53
3...38
3...53
HIGH-- PRESSURE SWITCH
(psig) Cut-- out Reset (Auto)
650 +/-- 15
420 +/-- 25
LOSS--OF--CHARGE / LOW--PRESSURE
SWITCH (Liquid Line) (psig) cut--out Reset
(auto)
20 +/-- 5
45 +/-- 10
RETURN ---AIR FILTERS†}
Throwaway Size in.
(mm)
20x20x1
508x508x25
20x24x1
508x610x25
24x30x1
610x762x25
