Dry Coil Air Delivery* -- Horizontal Discharge -- Unit 574D----A24--60
UNIT
HEATING
RISE RANG E
o
F(
o
C)
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STA TIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
574D(N,P,E)WA60115
30 --- 60
( 1 7 --- 3 3 )
Low Blue
CFM 1445 1389 1341 1281 1236 1189 1139 1072 1027
Heating Rise
(
o
F)
60 NA NA NA NA NA NA NA NA
Heating Rise
(
o
C)
33 NA NA NA NA NA NA NA NA
M e d --- L o w Pink
CFM 1678 1635 1602 1558 1513 1474 1438 1404 1349
Heating Rise
(
o
F)
52 53 54 56 57 59 60 NA NA
Heating Rise
(
o
C)
29 30 30 31 32 33 34 NA NA
Medium
2
Red
CFM 1962 1915 1880 1843 1794 1753 1711 1675 1628
Heating Rise
(
o
F)
44 45 46 47 48 50 51 52 53
Heating Rise
(
o
C)
25 25 26 26 27 28 28 29 30
M e d --- H i g h
1
Orange
CFM 2131 2088 2065 2013 1982 1941 1888 1860 1785
Heating Rise
(
o
F)
41 42 42 43 44 45 46 47 49
Heating Rise
(
o
C)
23 23 23 24 24 25 26 26 27
High Black
CFM 2461 2409 2339 2286 2192 2140 2062 1968 1874
Heating Rise
(
o
F)
35 36 37 38 40 41 42 44 46
Heating Rise
(
o
C)
20 20 21 21 22 23 23 25 26
574D(N,P,E)WA60130
35 --- 65
( 1 9 --- 3 6 )
Low Blue
CFM 1445 1389 1341 1281 1236 1189 1139 1072 1027
Heating Rise
(
o
F)
NA NA NA NA NA NA NA NA NA
Heating Rise
(
o
C)
NA NA NA NA NA NA NA NA NA
M e d --- L o w Pink
CFM 1678 1635 1602 1558 1513 1474 1438 1404 1349
Heating Rise
(
o
F)
57 59 60 62 64 65 NA NA NA
Heating Rise
(
o
C)
32 33 33 34 35 36 NA NA NA
Medium
2
Red
CFM 1962 1915 1880 1843 1794 1753 1711 1675 1628
Heating Rise
(
o
F)
49 50 51 52 54 55 56 57 59
Heating Rise
(
o
C)
27 28 28 29 30 31 31 32 33
M e d --- H i g h
1
Orange
CFM 2131 2088 2065 2013 1982 1941 1888 1860 1785
Heating Rise
(
o
F)
45 46 47 48 49 50 51 52 54
Heating Rise
(
o
C)
25 26 26 27 27 28 28 29 30
High Black
CFM 2461 2409 2339 2286 2192 2140 2062 1968 1874
Heating Rise
(
o
F)
39 40 41 42 44 45 47 49 51
Heating Rise
(
o
C)
22 22 23 23 24 25 26 27 29
*Air delivery values are without air filter and are for dry coil (See 574D --- ---A Wet Coil Pressure Drop table). 1
Factory-shipped heating speed
2
Factory-shipped cooling speed
”NA” = Not allowed for heating speed Note: Deduct field-supplied air filter pressure drop and wet coil pressure drop to obtain external static pressure available for ducting. Shaded areas indicate speed/static combinations that are not permitted for dehumidification speed.
