Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A24060
25 - 55
o
F
(14 - 31
o
C)
Low Blue
CFM 809 664 554 447 --- --- --- --- --- ---
WATTS 85 82 87 95 --- --- --- --- --- ---
BHP 0.09 0.09 0.09 0.10 --- --- --- --- --- ---
Heating
Rise (
o
F)
37 46 55 68 --- --- --- --- --- ---
Heating
Rise (
o
C)
21 25 30 38 --- --- --- --- --- ---
Med-Low Pink
CFM 875 787 693 612 498 392 --- --- --- ---
WATTS 101 111 115 125 131 142 --- --- --- ---
BHP 0.11 0.12 0.12 0.13 0.14 0.15 --- --- --- ---
Heating
Rise (
o
F)
35 38 44 49 NA NA --- --- --- ---
Heating
Rise (
o
C)
19 21 24 27 NA NA --- --- --- ---
Medium
2
Red
CFM 939 860 748 663 591 472 399 --- --- ---
WATTS 119 124 134 138 147 155 164 --- --- ---
BHP 0.13 0.13 0.14 0.15 0.16 0.17 0.18 --- --- ---
Heating
Rise (
o
F)
32 35 40 46 51 NA NA --- --- ---
Heating
Rise (
o
C)
18 20 22 25 28 NA NA --- --- ---
Med-High
1
Orange
CFM 1026 949 873 786 694 604 516 --- --- ---
WATTS 146 151 161 167 177 183 195 --- --- ---
BHP 0.16 0.16 0.17 0.18 0.19 0.20 0.21 --- --- ---
Heating
Rise (
o
F)
29 32 35 38 44 50 NA --- --- ---
Heating
Rise (
o
C)
16 18 19 21 24 28 NA --- --- ---
High Black
CFM 1264 1202 1134 1070 1002 931 870 806 699 610
WATTS 250 261 274 279 290 296 308 319 328 332
BHP 0.27 0.28 0.29 0.30 0.31 0.32 0.33 0.34 0.35 0.36
Heating
Rise (
o
F)
NA NA NA NA 30 32 35 37 43 50
Heating
Rise (
o
C)
NA NA NA NA 17 18 19 21 24 28
