Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A42060
25 - 55
o
F
(14 - 31
o
C)
Low
1
Blue
CFM 1365 1324 1284 1233 1181 1127 1084 1039 984 939
WATTS 177 189 201 210 222 236 248 261 269 281
BHP 0.19 0.20 0.22 0.23 0.24 0.25 0.27 0.28 0.29 0.30
Heating
Rise (
o
F)
NA 34 35 36 38 39 41 43 45 47
Heating
Rise (
o
C)
NA 19 19 20 21 22 23 24 25 26
Med-Low Pink
CFM 1425 1384 1339 1301 1254 1199 1151 1104 1065 1015
WATTS 197 210 223 235 248 257 271 284 296 305
BHP 0.21 0.23 0.24 0.25 0.27 0.28 0.29 0.30 0.32 0.33
Heating
Rise (
o
F)
NA NA NA 34 35 37 39 40 42 44
Heating
Rise (
o
C)
NA NA NA 19 20 21 21 22 23 24
Medium Red
CFM 1582 1549 1509 1469 1433 1392 1346 1300 1249 1213
WATTS 267 280 294 308 322 336 344 359 374 387
BHP 0.29 0.30 0.32 0.33 0.35 0.36 0.37 0.38 0.40 0.42
Heating
Rise (
o
F)
NA NA NA NA NA NA NA 34 36 37
Heating
Rise (
o
C)
NA NA NA NA NA NA NA 19 20 20
Med-High
2
Orange
CFM 1623 1586 1553 1511 1470 1433 1393 1350 1309 1261
WATTS 285 299 312 324 335 349 363 378 393 407
BHP 0.31 0.32 0.33 0.35 0.36 0.37 0.39 0.41 0.42 0.44
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA 34 35
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA 19 20
High Black
CFM 1775 1736 1696 1660 1622 1588 1557 1516 1472 1426
WATTS 371 386 401 410 424 439 453 468 483 497
BHP 0.40 0.41 0.43 0.44 0.45 0.47 0.49 0.50 0.52 0.53
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA NA NA
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA NA NA
