Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A48090
35 - 65
o
F
(19 - 36
o
C)
Low
1
Blue
CFM 1503 1457 1423 1374 1330 1287 1241 1199 1153 1111
WATTS 225 233 246 254 269 282 292 307 314 329
BHP 0.24 0.25 0.26 0.27 0.29 0.30 0.31 0.33 0.34 0.35
Heating
Rise (
o
F)
45 47 48 49 51 53 55 57 59 61
Heating
Rise (
o
C)
25 26 27 27 28 29 30 32 33 34
Med-Low Pink
CFM 1556 1508 1461 1432 1388 1346 1302 1256 1221 1168
WATTS 244 261 268 281 290 305 319 330 345 353
BHP 0.26 0.28 0.29 0.30 0.31 0.33 0.34 0.35 0.37 0.38
Heating
Rise (
o
F)
44 45 47 47 49 51 52 54 56 58
Heating
Rise (
o
C)
24 25 26 26 27 28 29 30 31 32
Medium
2
Red
CFM 1861 1822 1786 1758 1716 1688 1660 1619 1583 1539
WATTS 400 417 426 441 452 467 482 492 507 519
BHP 0.43 0.45 0.46 0.47 0.48 0.50 0.52 0.53 0.54 0.56
Heating
Rise (
o
F)
37 37 38 39 40 40 41 42 43 44
Heating
Rise (
o
C)
20 21 21 21 22 22 23 23 24 25
Med-High Orange
CFM 2319 2291 2255 2230 2193 2166 2118 2057 1992 1887
WATTS 758 769 787 799 808 823 822 805 780 737
BHP 0.81 0.82 0.84 0.86 0.87 0.88 0.88 0.86 0.84 0.79
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA NA 36
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA NA 20
High Black
CFM 2532 2487 2444 2391 2330 2259 2179 2111 2033 1949
WATTS 1014 1022 1015 994 965 935 898 858 823 786
BHP 1.09 1.10 1.09 1.07 1.03 1.00 0.96 0.92 0.88 0.84
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA NA 35
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA NA 19
