Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A60115
30 - 60
o
F
(17 - 33
o
C)
Low
1
Blue
CFM 1479 1436 1387 1346 1298 1253 1206 1160 1114 1061
WATTS 224 239 247 262 270 284 300 307 319 330
BHP 0.24 0.26 0.26 0.28 0.29 0.30 0.32 0.33 0.34 0.35
Heating
Rise (
o
F)
46 47 49 51 52 54 56 59 NA NA
Heating
Rise (
o
C)
26 26 27 28 29 30 31 33 NA NA
Med-Low Pink
CFM 1841 1796 1761 1724 1690 1651 1616 1578 1527 1478
WATTS 425 434 453 460 476 485 501 508 525 542
BHP 0.46 0.47 0.49 0.49 0.51 0.52 0.54 0.54 0.56 0.58
Heating
Rise (
o
F)
37 38 39 39 40 41 42 43 45 46
Heating
Rise (
o
C)
21 21 21 22 22 23 23 24 25 26
Medium
2
Red
CFM 1944 1913 1872 1838 1801 1771 1731 1698 1655 1613
WATTS 486 501 511 529 537 554 565 578 595 603
BHP 0.52 0.54 0.55 0.57 0.58 0.59 0.61 0.62 0.64 0.65
Heating
Rise (
o
F)
35 36 36 37 38 38 39 40 41 42
Heating
Rise (
o
C)
19 20 20 21 21 21 22 22 23 23
Med-High Orange
CFM 2178 2148 2105 2073 2036 2002 1967 1919 1845 1751
WATTS 674 691 703 717 733 743 758 754 734 701
BHP 0.72 0.74 0.75 0.77 0.79 0.80 0.81 0.81 0.79 0.75
Heating
Rise (
o
F)
NA NA NA NA NA 34 35 35 37 39
Heating
Rise (
o
C)
NA NA NA NA NA 19 19 20 20 22
High Black
CFM 2480 2432 2375 2322 2236 2161 2085 2006 1917 1808
WATTS 1029 1012 995 975 941 908 869 836 796 751
BHP 1.10 1.09 1.07 1.05 1.01 0.97 0.93 0.90 0.85 0.81
Heating
Rise (
o
F)
NA NA NA NA NA NA NA 34 35 38
Heating
Rise (
o
C)
NA NA NA NA NA NA NA 19 20 21
