Bryant 581J series User Manual

37
581J*24 COOLING CAPACITIES, SUBCOOLING MODE
581J*24 COOLING CAPACITIES, HOT GAS REHEAT MODE
LEGEND
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - CFM
6,000 8,000 10,000
Air Entering Evaporator - Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC
281.60 256.50 231.30 293.10 267.00 240.90 302.30 275.40 248.60
SHC
114.70 141.00 167.40 140.60 166.60 192.60 161.60 187.30 212.90
kW
13.52 13.25 12.95 13.82 13.46 13.21 13.97 13.60 13.31
85
TC
261.30 236.90 212.40 272.10 247.70 221.30 280.70 254.60 228.50
SHC
90.90 123.50 156.10 118.80 151.10 183.30 141.40 173.40 205.40
kW
14.95 14.68 14.48 15.25 14.89 14.64 15.40 15.03 14.74
95
TC
241.10 217.20 193.40 251.10 226.40 201.70 259.20 233.80 208.40
SHC
67.20 106.00 144.80 97.10 120.10 174.10 121.20 159.50 197.80
kW
16.52 16.25 15.95 16.82 16.46 16.21 16.97 16.60 16.31
105
TC
220.80 197.50 174.40 230.20 206.20 182.20 237.70 213.00 188.40
SHC
43.40 88.40 133.50 75.30 120.10 164.90 101.00 145.70 178.90
kW
18.09 17.82 17.52 18.39 18.03 17.78 18.54 18.17 17.88
115
TC
200.50 178.00 155.50 209.20 185.90 162.60 216.20 192.20 168.70
SHC
19.70 70.90 122.20 53.50 104.60 155.70 80.90 131.80 161.20
kW
19.65 19.38 19.08 19.95 19.59 19.34 20.10 19.73 19.44
125
TC
180.20 158.40 136.50 188.20 165.60 143.00 194.70 171.40 148.20
SHC
-4.10 53.40 110.80 31.70 89.10 142.20 60.70 118.00 145.10
kW
20.59 20.32 20.02 20.89 20.53 20.28 21.04 20.67 20.38
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator - Cfm
6,000 8,000 10,000 6,000 8,000 10,000 6,000 8,000 10,000
80
TC
115.20 123.30 130.60 120.40 129.30 138.20 122.80 135.00 143.70
SHC
40.80 58.30 76.10 32.30 45.50 60.40 20.10 34.30 48.00
kW
13.24 13.32 13.39 13.43 13.57 13.65 13.49 13.68 13.74
75
TC
119.80 128.60 135.90 125.50 135.30 143.20 128.00 139.50 148.40
SHC
45.60 62.80 82.10 37.00 49.80 65.20 24.30 38.70 52.60
kW
13.05 13.10 13.17 13.21 13.35 13.43 13.27 13.46 13.52
70
TC
122.50 133.10 140.20 129.80 140.70 147.60 132.40 144.40 153.20
SHC
49.80 76.00 86.10 41.10 54.30 69.20 28.80 41.40 56.80
kW
12.80 12.87 12.94 12.98 13.12 13.20 13.04 13.23 13.29
60
TC
133.80 142.50 149.60 139.30 150.40 157.40 141.50 154.20 163.00
SHC
58.60 76.00 95.00 50.20 63.50 78.10 37.80 52.10 65.90
kW
12.34 12.42 12.49 12.53 12.67 12.75 12.59 12.78 12.84
50
TC
143.50 151.80 159.30 149.00 160.00 167.00 151.30 163.60 172.50
SHC
67.70 84.80 103.80 59.10 72.40 87.00 46.70 61.00 74.90
kW
11.88 11.95 12.03 12.07 12.21 12.29 12.13 12.32 12.38
40
TC
153.20 161.30 168.70 158.60 169.20 176.60 160.80 173.10 182.00
SHC
76.50 93.60 111.60 68.00 81.50 95.80 55.80 69.80 84.00
kW
11.42 11.49 11.56 11.60 11.74 11.82 11.66 11.85 11.91
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Kilowatts
SHC — Sensible Heat Capacity
TC — Total Capacity
