581J*28 COOLING CAPACITIES, SUBCOOLING MODE
581J*28 COOLING CAPACITIES, HOT GAS REHEAT MODE
LEGEND
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - CFM
7,500 10,000 12,500
Air Entering Evaporator - Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC
351.30 319.50 287.80 370.40 337.30 304.10 385.80 351.50 317.20
SHC
166.50 199.40 232.30 191.20 245.60 258.50 211.40 245.60 279.90
kW
16.75 16.55 15.20 17.30 16.75 15.85 17.80 17.50 16.50
85
TC
327.50 296.40 265.30 346.10 313.60 281.20 361.10 327.50 294.00
SHC
137.40 178.20 219.00 162.60 204.50 246.40 183.30 226.00 268.70
kW
18.65 18.45 17.25 19.20 18.65 17.80 19.45 19.15 18.15
95
TC
303.70 273.30 242.90 321.80 290.00 258.30 336.40 303.50 270.70
SHC
108.20 157.00 205.80 134.00 184.10 234.30 155.10 206.40 257.60
kW
20.60 20.40 19.34 21.15 20.60 19.95 21.60 21.30 20.30
105
TC
279.90 250.20 220.40 297.50 266.40 235.30 311.70 279.50 247.40
SHC
79.00 135.80 192.50 105.40 163.80 222.20 127.10 186.70 246.40
kW
22.85 22.65 21.45 23.40 22.85 22.05 23.70 23.40 22.40
115
TC
256.20 227.10 198.00 273.20 242.80 212.40 287.00 255.50 224.10
SHC
49.90 114.50 179.20 76.80 143.40 210.10 98.90 167.10 223.80
kW
25.05 24.85 23.65 25.60 25.05 24.25 25.90 25.60 24.60
125
TC
232.40 203.90 175.50 248.90 219.20 189.50 262.30 231.50 200.80
SHC
20.70 93.30 166.00 48.20 123.10 188.90 70.80 147.40 200.80
kW
27.25 27.05 25.80 27.80 27.25 26.50 28.15 27.85 26.85
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator - Cfm
7,500 10,000 12,500 7,500 10,000 12,500 7,500 10,000 12,500
80
TC
124.40 133.90 139.00 132.00 142.10 145.10 135.60 149.10 151.50
SHC
37.60 60.70 82.20 27.80 45.40 65.80 17.50 34.20 50.10
kW
15.83 15.90 16.00 15.97 16.13 16.16 16.11 16.31 16.38
75
TC
129.00 138.50 144.60 136.60 147.60 150.10 140.60 154.00 156.30
SHC
47.10 70.60 92.10 37.30 55.30 75.70 27.00 43.70 60.00
kW
15.77 15.83 15.94 15.91 16.07 16.10 16.05 16.25 16.32
70
TC
133.60 143.10 149.20 141.20 152.30 154.80 145.30 158.80 161.10
SHC
57.30 80.70 102.20 47.50 65.40 85.80 37.20 53.90 70.10
kW
15.68 15.75 15.86 15.83 16.00 16.04 15.88 16.08 16.15
60
TC
142.80 158.40 158.40 150.40 161.40 163.90 153.90 167.40 169.70
SHC
76.50 121.40 121.40 66.70 84.60 105.00 56.40 73.10 89.30
kW
15.54 15.60 15.71 15.68 15.84 15.87 15.82 16.02 16.09
50
TC
151.80 161.30 167.40 159.40 170.50 173.20 162.80 176.20 178.80
SHC
94.10 117.50 139.00 84.30 102.20 122.60 74.00 90.70 106.90
kW
15.40 15.47 15.58 15.54 15.68 15.71 15.66 15.86 15.93
40
TC
161.20 170.70 176.80 168.80 179.80 182.50 172.20 185.70 188.20
SHC
114.10 137.60 159.10 104.30 122.30 142.70 94.00 110.70 127.00
kW
15.24 15.31 15.42 15.39 15.55 15.58 15.53 15.73 15.80
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Kilowatts
SHC — Sensible Heat Capacity
TC — Total Capacity
