Bryant 597 - Unit Dimensions and Installation Clearances; Installation Clearance Requirements; Dimensional Specifications and Mounting

—2—
DIMENSIONS
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS
MINIMUM MOUNTING
PAD DIMENSIONSABCDEFGHKLMN
018 F, G 33-13/16 22-1/2 26-3/16 4-1/8 7-1/8 21-15/16 28-3/8 5/8 9-1/4 17-3/8 13-1/2 2-3/8 20 x 27 024 F, G 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 5/8 16-1/2 20-3/8 11 2-15/16 26 x 32 030 F, G 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 3/4 16-1/2 20-3/8 13-1/2 2-15/16 26 x 32 036 F, G 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 3/4 16-1/2 20-3/8 13-1/2 2-15/16 26 x 32 042 F, G 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16-1/2 20-3/8 15 2-15/16 26 x 32 048 F, H 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16-1/2 20-3/8 15 2-15/16 26 x 32 060 F, G 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16-1/2 20-3/8 15 2-15/16 26 x 32
ACCESS
PANEL
1
1
/4"
1. Allow 30 in. clearance to service end of unit, 48 in. above unit, 6 in. on one side, 12 in. on remaining side,
and 24 in. between units for proper airflow. Minimum outdoor operating ambient in cooling mode is 55°F (unless low-ambient control is used) max 125°F.2. Series designation is the 14th position of the unit model number.3. Center of gravity .4.
NOTES:
AIR DISCHARGE
AIR DISCHARGE
AIR IN
AIR IN
AIR IN
2
1
/2"
AIR DISCHARGE
1
3
/4"
4
3
/16"
3
/8-IN. DIA LIQUID
LINE CONN
H DIA VAPOR
LINE CONN
8
3
/16"
7
/8-IN. DIA HOLE
FIELD POWER SUPPLY CONN
7
/8-IN. DIA
HOLE WITH 1
1
/8-IN. DIA KNOCKOUT
AND 1
3
/8-IN. DIA KNOCKOUT
3
/8-IN. DIA TIEDOWN KNOCKOUTS
(2) PLACES IN BASEPAN
10
1
/2"
FIELD CONTROL SUPPLY CONN
1
9
/16"
L
C
F
N
G
A
B
M
K
E
D
C
L
A97082
