RECOMMENDED TUBE DIAMETERS
* For tube sets between 50 and 175 ft or 20 ft vertical differential, consult Residential Split System Long-Line Application Guideline.
CHECK-FLO-RATER® PISTON
* Piston listed is for any approved non-capillary tube coil combination. Piston
is shipped with outdoor unit and must be installed in an approved indoor
coil.
CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE)
UNIT
SIZE
Liquid Tube Diameter (In.) Vapor Tube Diameter (In.)
0 to 50 Ft
Tube Length Long-Line Applications
*
0 to 50 Ft
Tube Length
Long-Line Applications *
(Maximum Diameter)
018, 024
3/8 3/8
5/8 3/4
030, 036 3/4 7/8
042, 048 7/8 1-1/8
060 1-1/8 1-1/8
UNIT SIZE-SERIES
PISTON
*
IDENTIFICATION NO.
018-F, G 55
024-F, G 61
030-F, G 67
036-F, G 76
042-F, G 82
048-F, H 93
060-F, G 101
UNIT SIZE-SERIES REQUIRED SUBCOOLING (°F)
018-F, G 10
024-F, G 12
030-F, G 15
036-F, G 12
042-F, G 12
048-F, H 11
060-F, G 12
CERTIFICATION APPLIES
ONLY WHEN THE
COMPLETE SYSTEM
IS LISTED WITH ARI.
REGISTERED QUALITY SYSTEM
As an ENERGY STAR®
Partner, Bryant Heating
& Cooling Systems has
determined that this
product meets the
ENERGY STAR®
guidelines for energy
efficiency.
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
1
0
U
N
I
T
A
R
Y
A
I
R
C
O
N
D
I
T
I
O
N
I
N
G
E
Q
U
I
P
M
E
N
T
*
Refer to the combination ratings in the product data sheet for system combinations meeting ENERGY STAR® efficiency standards.
*
