DETAILED COOLING CAPACITIES* Continued
See notes on page 25.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN048-F, H Outdoor Section With CC5A/CD5AA060 Indoor Section continued
1400
72 53.5 25.8 4.09 51.5 25.1 4.58 49.4 24.3 5.13 47.1 23.4 5.69 44.7 22.5 6.31
67 48.9 32.2 4.04 47.1 31.4 4.53 45.0 30.6 5.05 43.0 29.7 5.62 40.8 28.8 6.23
62 44.6 38.5 4.00 42.9 37.7 4.48 41.0 36.7 4.99 39.0 35.8 5.55 37.0 34.8 6.14
57 41.8 41.8 3.97 40.4 40.4 4.44 39.0 39.0 4.96 37.5 37.5 5.52 35.9 35.9 6.12
1600
72 54.6 26.9 4.17 52.5 26.1 4.67 50.3 25.3 5.21 47.8 24.4 5.78 45.4 23.5 6.41
67 50.0 34.1 4.12 48.0 33.3 4.62 45.9 32.4 5.14 43.7 31.5 5.71 41.4 30.6 6.32
62 45.6 41.0 4.08 43.7 40.1 4.56 41.8 39.1 5.08 39.8 38.1 5.64 37.8 36.9 6.23
57 43.5 43.5 4.06 42.0 42.0 4.55 40.5 40.5 5.06 38.9 38.9 5.63 37.3 37.3 6.23
1800
72 55.5 27.9 4.25 53.2 27.1 4.75 51.0 26.3 5.30 48.5 25.4 5.87 45.9 24.5 6.50
67 50.8 35.8 4.21 48.7 35.0 4.69 46.5 34.1 5.22 44.3 33.2 5.79 42.0 32.3 6.41
62 46.3 43.3 4.16 44.5 42.3 4.64 42.5 41.2 5.17 40.5 39.9 5.73 38.4 38.4 6.33
57 44.9 44.9 4.15 43.4 43.4 4.63 41.8 41.8 5.16 40.1 40.1 5.73 38.3 38.3 6.32
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
COILS + 355MAV042080 VARIABLE SPEED FURNACE
CC5A/CD5AW 060 1.00 0.96
CD5AA 048 0.98 0.97 CD5AA 048 0.98 0.96
CK3BA 048 0.98 0.97 CK3BA 048 0.98 0.96
CK5A/CK5BA 048 0.98 0.97 060 0.98 0.96
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK5A/CK5BA 048 0.98 0.96
CC5A/CD5AA 060 0.98 0.98 CK5A/CK5BX 060 1.00 0.96
CC5A/CD5AW 060 1.00 0.98
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CD5AA 048 0.98 0.98 CC5A/CD5AA 060 0.98 0.96
CK3BA 048 0.98 0.98 CC5A/CD5AW 048 0.98 0.96
CK5A/CK5BA 048 0.98 0.98 060 1.00 0.95
060 0.98 0.98 CK5A/CK5BA 060 0.98 0.96
CK5A/CK5BX 060 1.00 0.98 CK5A/CK5BW 048 0.98 0.96
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK5A/CK5BX 060 1.00 0.96
CC5A/CD5AC 048 0.96 0.97 —— —
