Table 8 — Information Enquiry
When the air conditioner enters the INFORMATION ENQUIRY status, it displays the code value for 25 seconds (see Table 9).
Table 9 — Information Enquiry
ENQUIRY INFORMATION DISPLAYING CODE MEANING
T1 T1 T1 temp.
T2 T2 T2 temp.
T3 T3 T3 temp.
T4 T4 T4 temp.
T2B Tb T2B temp.
TP TP TP temp.
TH TH TH temp.
Targeted Frequency FT Targeted Frequency
Actual Frequency Fr Actual Frequency
Indoor Fan Speed IF Indoor fan speed
Outdoor Fan Speed OF Outdoor fan speed
EXV Opening Angle LA EXV opening angle
Compressor continuous running time CT Compressor continuous running time
Compressor stop causes ST Compressor stop causes
Reserve A0
Reserve A1
Reserve b0
Reserve b1
Reserve b2
Reserve b3
Reserve b4
Reserve b5
Reserve b6
Reserve dL
Reserve Ac
Reserve Uo
Reserve Td
ENQUIRY INFORMATION DISPLAY VALUE MEANING REMARK
T1,T2,T3,T4, T2B,TP,TH,
Targeted Frequency,
Actual Frequency
-1F,-1E,-1d,-1c,-1b,-1A -25,-24,-23,-22,-21,-20
1. The displaying temperature is the
actual value.
2. The temperature is °C no matter what
kind of remote controller is used.
3. T1,T2,T3,T4,T2B display range:-
25~70, TP display range: -20~130.
4. Frequency display range: 0~159HZ.
5. If the actual value exceeds the range, it
displays the maximum value or mini-
mum value.
-19—99 -19—99
A0,A1,…A9 100,101,…109
b0,b1,…b9 110,111,…119
c0,c1,…c9 120,121,…129
d0,d1,…d9 130,131,…139
E0,E1,…E9 140,141,…149
F0,F1,…F9 150,151,…159
Indoor fan speed/Outdoor fan speed
0OFF
1,2,3,4
Low speed, Medium speed, High speed,
Turbo
For some big capacity motors.
14-FF
Actual fan speed = Display value turns to
decimal value and then multiply 10.
The unit is RPM.
For some small capacity motors, the
display value is from 14-FF
(hexadecimal), the corresponding fan
speed range is from 200-2550 RPM.
EXV opening angle 0-FF
Actual EXV opening value = Display
value turns to decimal value and then
multiply by 2.
Compressor continuous running time 0-FF 0-255 minutes
If the actual value exceeds the range, it
displays the maximum value or minimum
value.
Compressor stop causes 0-99
For the detailed meaning, consult with an
engineer
Decimal display
Reserve 0-FF
