SG-619AHB-01: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
39
DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
7) Pull the two sides of the bottom panel
along the direction shown in the
image to the right to remove it.
8) Pull the panel’s support bar to remove it.
9) Remove the panel assembly.
Caution: If you want to close the panel, you
must bend the middle of the support bar,
otherwise it will break. For 6K~18K models,
the support bar is located on the left of the
unit. For 24K and up, it it located in the
middle of the unit.
