SG-619AHB-01: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
40
DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
10) Remove 1 screw from the display board.
11) Rotate the display board subassembly
in the direction shown in the picture to
the right.
12) Pull the four clips to remove the
display board.
