SG-619AHB-01: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
43
DISASSEMBLY INSTRUCTIONS (CONT)
Procedure Illustration
7) Remove the other screw used for the
ground connection.
8) Collapse the support bar.
9) Pull the electronic control box cover
along the direction shown in the
image to the right to remove it.
10) Remove one screw then pull out
the electronic control box subassembly.
Ground Screw
To Next Page
