DISASSEMBLY INSTRUCTIONS (CONT)
Evaporator
NOTE: Remove the front panel, electrical parts and the fan.
Procedure Illustration
1) Remove the 2 screws and then remove the
panel frame assembly.
2) Disassemble the pipe clamp board.
